Rohde & Schwarz FSH13
| Attribute | Value |
|---|---|
| Frequency Range | 100 kHz to 13.6 GHz |
| Dynamic Range | Up to 110 dB |
| Display | 10.1-inch color touchscreen, 1280 x 800 pixels |
| Battery Life | Up to 4 hours of operation with internal battery |
| Weight | Approximately 4.0 kg (8.8 lbs) including battery |
| DANL (Displayed Average Noise Level) | -163 dBm (typ.) with preamplifier enabled |
| Phase Noise | -100 dBc/Hz at 10 kHz offset (typ.) at 1 GHz |
| Resolution Bandwidth (RBW) | 1 Hz to 3 MHz |
| Interfaces | USB, LAN (Ethernet), GPS receiver (optional), WLAN (optional) |
| Operating Temperature Range | -10°C to +55°C (14°F to 131°F) |
Rohde & Schwarz FSH13 Options:
- FSH13 - FSH-B1 - Distance-to-Fault Measurement (includes 1 m cable, R&S FSH-Z2 required)
- FSH13 - FSH-K1 - Remote Control via RS-232-C
- FSH13 - FSH-K2 - Vector Transmission and Reflection Measurements
- FSH13 - FSH-K3 - Receiver Mode
| Model | FSH13 |
|---|
The Rohde and Schwarz FSH13 is a rugged, portable spectrum analyzer offering a wide frequency range from 9 kHz to 13.6 GHz. With high sensitivity, low measurement uncertainty, and 20 MHz demodulation bandwidth, it efficiently handles LTE signal analysis, RF maintenance, and installation tasks. This versatile device includes a power meter, cable and antenna tester, and a two-port vector network analyzer.
Ideal for outdoor use, it supports RF analysis, signal quality assessment, and electric field strength measurements, featuring user-configurable automatic test sequences and a splash-proof housing.
Testwall can supply the used Rohde and Schwarz FSH13, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde and Schwarz FSH13.
