Rohde & Schwarz NRP-Z28
| Attribute | Value |
|---|---|
| Frequency Range | 10 MHz to 18 GHz |
| Video Bandwidth | >50 kHz (100 kHz typ.) |
| Rise Time | <8 µs (4 µs typ.) |
| Connector | Type-N male |
| Interfaces | USB (full speed) |
| Sensor Type | 3-path diode with power splitter, level control |
| Power Range | 200 pW to 100 mW (-67 to +20 dBm) |
| Maximum Power | 700 mW average, 4 W peak (10 µs) |
| SWR | output <1.11 (to 2.4 GHz), <1.15 (to 4 GHz), <1.22 (to 8 GHz), <1.30 (to 18 GHz) |
| Compatible Meters | NRP2, NRX, NRP-Z4 USB adapter (PC), ODU Mini-Snap R&S instruments |
| Dimensions | 48 × 50 × 250 mm |
| Weight | <0.7 kg |
Compatible power meters
The Rohde and Schwarz NRP-Z28 is a specialized directional power sensor with an integrated power splitter, operating across a frequency range of 10 MHz to 18 GHz and measuring power levels from -67 dBm to +20 dBm. Designed with an N connector, it serves as an all-in-one solution combining the functions of a classic power splitter and power sensor.
This sensor is ideal for applications needing highly precise signal input levels, such as calibrating measuring receivers or improving the absolute level accuracy of signal generators.
Testwall can supply the used Rohde and Schwarz NRP-Z28, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde and Schwarz NRP-Z28.
