Rohde & Schwarz NRP40SN
| Attribute | Value |
|---|---|
| Frequency Range | 50 MHz to 40 GHz |
| Video Bandwidth | >100 kHz (150 kHz typ.) |
| Rise Time | <5 µs (3 µs typ.) |
| Connector | 2.92 mm male |
| Interfaces | USB, LAN (PoE) |
| Sensor Type | peak and average (3-path diode) |
| Power Range | 100 pW to 100 mW (-70 to +20 dBm) |
| Maximum Power | 200 mW average, 1 W peak (10 µs) |
| SWR | <1.13 (50 MHz to 2.4 GHz), <1.20 (to 8 GHz), <1.25 (to 18 GHz), <1.30 (to 26.5 GHz), <1.35 (to 33 GHz), <1.37 (to 40 GHz) |
| Compatible Meters | NRX, NRP2 (legacy mode), PC via USB |
| Dimensions | 73 × 26 × 146 mm |
| Weight | <0.35 kg |
Compatible power meters
Rohde & Schwarz NRP40SN Options:
- NRP40SN - NRP-Z4 - USB adapter cable (passive)
- NRP40SN - NRP-Z3 - USB adapter cable (active)
- NRP40SN - NRPZ-K1 - R&S®NRPV license for one sensor
- NRP40SN - NRP-Z5 - Sensor hub
The Rohde & Schwarz NRP40SN is a 3-path diode power sensor with LAN interface, covering a frequency range of 50 MHz to 40 GHz and a dynamic power level from -70 dBm to +20 dBm. Featuring a 2.92 mm male connector, it operates efficiently over LAN with PoE support or through a PoE switch. The sensor ensures precision with intelligent averaging and versatile measurement capabilities.
Ideal for high-frequency power measurements, this sensor minimizes measurement uncertainty and supports fast data acquisition. Use with compatible accessories for seamless integration into test systems.
Testwall can supply the used Rohde & Schwarz NRP40SN, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde & Schwarz NRP40SN.
