Rohde & Schwarz NRP40T
| Attribute | Value |
|---|---|
| Frequency Range | 50 MHz to 40 GHz |
| Power Measurement Range | -35 dBm to +26 dBm |
| Connector Type | 2.92 mm (K) male |
| Measurement Uncertainty | ±0.9 dB (typical) |
| Sensor Technology | Thermal (Thermocouple-based) |
| Interface | USB 2.0 |
| Operating Temperature Range | 0 °C to +55 °C |
| Storage Temperature Range | -40 °C to +70 °C |
| Maximum Input Power (Continuous) | 200 mW (+23 dBm) |
| Dimensions (L x W x H) | Approximately 155 mm x 30 mm x 20 mm |
| Model | NRP40T |
|---|
The Rohde and Schwarz NRP40T is a thermal power sensor offering a frequency range from DC to 40 GHz and a power level range from -35 dBm to +20 dBm. It features a 2.92 mm (male) connector and requires an R&S NRP-ZKU or NRP-ZK6 cable for connectivity. The sensor delivers superior precision for reference applications, tolerates any modulation, and is designed to minimize measurement noise while being immune to thermal environmental effects.
This sensor is ideal for high-frequency power measurements and ensures stable readings in various testing environments. It's compatible with USB connectivity through dedicated R&S cables.
Testwall can supply the used Rohde and Schwarz NRP40T, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde and Schwarz NRP40T.
