Rohde & Schwarz NRP8S
| Attribute | Value |
|---|---|
| Frequency Range | 10 MHz to 8 GHz |
| Power Measurement Range | -60 dBm to +20 dBm |
| Connector Type | N-Type (female) |
| Measurement Uncertainty | ± 0.9 dB (at maximum frequency and power level) |
| Interface | USB 2.0 |
| VSWR | ≤ 1.15 (typical, at 8 GHz) |
| Zeroing Time | ≤ 2 seconds (typical) |
| Operating Temperature Range | 0 °C to +55 °C |
| Sensor Technology | Three-path diode power sensor |
| Compatible Instruments | Rohde & Schwarz NRP2, NRPV, NRP-Z5, and USB-based power meter systems |
Rohde & Schwarz NRP8S Options:
- NRP8S - NRP-Z4 - USB adapter cable (passive)
- NRP8S - NRP-Z3 - USB adapter cable (active)
- NRP8S - NRPZ-K1 - R&S NRPV license for one sensor
- NRP8S - NRP-Z5 - Sensor hub
| Model | NRP8S |
|---|
The Rohde & Schwarz NRP8S is a power sensor operating from 10 MHz to 8 GHz with a dynamic range of –70 dBm to +23 dBm, offering precision measurements from 100 pW to 200 mW. With over 50,000 readings per second and up to 10,000 triggered measurements/s, it ensures rapid data acquisition. Featuring detachable cables with various connectors like USB, it allows flexible integration and high measurement accuracy across the entire level range.
Ideal for low-level signal analysis, the NRP8S supports fast and precise testing with its Trigger I/O port directly on the sensor and compatibility with NRP2 base units, PCs, and Rohde & Schwarz instruments.
Testwall can supply the used Rohde & Schwarz NRP8S, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde & Schwarz NRP8S.
