Rohde & Schwarz
Rohde & Schwarz NRV-Z34
Peak Power Sensor 30 MHz to 6 GHz
10 MHz to 18 GHz Frequency Range
-35 dBm to +20 dBm Power Measurement Range
N-type (female) Connector Type
Diode Power Sensor Sensor Type
±0.9 dB (typical) Measurement Uncertainty
| Attribute | Value |
|---|---|
| Frequency Range | 10 MHz to 18 GHz |
| Power Measurement Range | -35 dBm to +20 dBm |
| Connector Type | N-type (female) |
| Sensor Type | Diode Power Sensor |
| Measurement Uncertainty | ±0.9 dB (typical) |
| SWR (Standing Wave Ratio) | ≤ 1.15 (10 MHz to 2 GHz), ≤ 1.25 (2 GHz to 18 GHz) |
| Operating Temperature Range | 0 °C to +55 °C |
| Compatible Instruments | Rohde & Schwarz NRV, NRVS, NRVD Power Meters |
| Impedance | 50 Ω |
| Maximum Input Power (Damage Level) | +23 dBm (200 mW) |
| Model | NRV-Z34 |
|---|
The Rohde and Schwarz NRV-Z34 is a power sensor designed for seamless integration with R&S®NRVS and R&S®NRVD base units. It supports absolute calibration with direct plug-in capability, allowing precise and instant measurements without external adjustments.
Equipped with built-in memory, the NRV-Z34 stores calibration data tailored to each sensor, ensuring accurate performance and simplifying usage in lab and field applications.
Testwall can supply the used Rohde and Schwarz NRV-Z34, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde and Schwarz NRV-Z34.
