Rohde & Schwarz RTM1052
Digital Oscilloscope - 2 channels, Bandwidth > 500 MHz
500 MHz Bandwidth
2 Number of Channels
2.5 GSa/s Sample Rate
10 Mpts (per channel) Memory Depth
10-bit ADC Vertical Resolution
| Attribute | Value |
|---|---|
| Bandwidth | 500 MHz |
| Number of Channels | 2 |
| Sample Rate | 2.5 GSa/s |
| Memory Depth | 10 Mpts (per channel) |
| Vertical Resolution | 10-bit ADC |
| Vertical Sensitivity | 1 mV/div to 10 V/div |
| Time Base Range | 1 ns/div to 50 s/div |
| Display | 10.1-inch capacitive touchscreen, WXGA (1280 x 800) |
| Input Impedance | 1 MΩ / 50 Ω (switchable) |
| Waveform Update Rate | Up to 50,000 waveforms/second |
Rohde & Schwarz RTM1052 Options:
- RTM2000 - B1 - Mixed Signal Option, 400 MHz (16 digital channels)
- RTM2000 - B10 - GPIB Interface
- RTM2000 - B201 - Bandwidth Upgrade from 200 MHz to 350 MHz
- RTM2000 - B202 - Bandwidth Upgrade from 200 MHz to 500 MHz
- RTM2000 - B203 - Bandwidth Upgrade from 200 MHz to 1 GHz
- RTM2000 - B200 - Bandwidth Upgrade from 350 MHz to 500 MHz
- RTM2000 - B204 - Bandwidth Upgrade from 350 MHz to 1 GHz
- RTM2000 - B205 - Bandwidth Upgrade from 500 MHz to 1 GHz
- RTM2000 - PK1 - Application Package (K1, K2, K3, K5, K6, K7, K15, K31, K32)
- RTM2000 - K1 - I²C/SPI Serial Triggering and Decoding
- RTM2000 - K2 - UART/RS-232/RS-422/RS-485 Serial Triggering and Decoding
- RTM2000 - K3 - CAN/LIN Serial Triggering and Decoding
- RTM2000 - K5 - I²S/LJ/RJ/TDM Serial Triggering and Decoding
- RTM2000 - K6 - MIL-STD-1553 Serial Triggering and Decoding
- RTM2000 - K7 - ARINC429 Serial Triggering and Decoding
- RTM2000 - K15 - History and Segmented Memory (460 Msample)
- RTM2000 - K18 - Spectrum Analysis and Spectrogram
- RTM2000 - K31 - Power Analysis
- RTM2000 - K32 - Digital Voltmeter (DVM)
| Model | RTM1052 |
|---|
The Rohde and Schwarz RTM1052 is designed for rapid fault detection with advanced signal analysis tools and an intuitive smart interface. This 500 MHz digital oscilloscope offers reliable performance for high-speed measurements.
Ideal for signal fault diagnosis and debugging, the RTM1052 simplifies analysis with precision tools and a user-friendly operating concept.
Testwall can supply the used Rohde and Schwarz RTM1052, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde and Schwarz RTM1052.
