Rohde & Schwarz
Rohde & Schwarz RTO2033
3 GHz, 2 Channels Oscilloscope
3 GHz Bandwidth
3 Number of Channels
10 Gsample/s (single channel), 5 Gsample/s (all channels) Sample Rate
200 Mpoints (standard), up to 800 Mpoints (optional) Memory Depth
8 bit (up to 16 bit with high resolution mode) Vertical Resolution
| Attribute | Value |
|---|---|
| Bandwidth | 3 GHz |
| Number of Channels | 3 |
| Sample Rate | 10 Gsample/s (single channel), 5 Gsample/s (all channels) |
| Memory Depth | 200 Mpoints (standard), up to 800 Mpoints (optional) |
| Vertical Resolution | 8 bit (up to 16 bit with high resolution mode) |
| Input Impedance | 50 Ω / 1 MΩ |
| Display | 12.1-inch capacitive touchscreen, 1280 x 800 resolution |
| Waveform Update Rate | Up to 1,000,000 waveforms/second |
| Time Base Range | 25 ps/div to 10,000 s/div |
| Connectivity | USB, LAN (LXI), HDMI, DisplayPort |
Rohde & Schwarz RTO2033 Options:
- RTO2033 - RTO-B1 - Mixed Signal Option, 400 MHz, additional 16 logic channels
- RTO2033 - RTO-B4 - OCXO 10 MHz, precision reference frequency with reference input and output connectors
- RTO2033 - RTO-B6 - Arbitrary Waveform Generator, 100 MHz, 2 analog channels, 8-bit pattern generator
- RTO2033 - RTO-B10 - GPIB Interface
- RTO2033 - RTO-B19 - Additional Solid State Disk
- RTO2033 - RTO-B101 - Memory Upgrade, 100 Msample per channel
- RTO2033 - RTO-B102 - Memory Upgrade, 200 Msample per channel
- RTO2033 - RTO-B104 - Memory Upgrade, 400 Msample per channel
- RTO2033 - RTO-B110 - Memory Upgrade, 1 Gsample per channel
- RTO2033 - RTO-K1 - I2C/SPI Serial Decoding
- RTO2033 - RTO-K2 - UART/RS-232/RS-422/RS-485 Serial Decoding
- RTO2033 - RTO-K3 - CAN/LIN Serial Triggering and Decoding
- RTO2033 - RTO-K4 - FlexRay Serial Triggering and Decoding
- RTO2033 - RTO-K5 - I2S Serial Triggering and Decoding
- RTO2033 - RTO-K6 - MIL-STD-1553 Serial Triggering and Decoding
- RTO2033 - RTO-K7 - ARINC 429 Serial Triggering and Decoding
- RTO2033 - RTO-K8 - Ethernet Serial Decoding
- RTO2033 - RTO-K9 - CAN-FD Serial Triggering and Decoding
- RTO2033 - RTO-K10 - SENT Serial Triggering and Decoding
- RTO2033 - RTO-K11 - I/Q Software Interface
- RTO2033 - RTO-K12 - Jitter Analysis
- RTO2033 - RTO-K13 - Clock Data Recovery (CDR)
- RTO2033 - RTO-K17 - High Definition Mode
- RTO2033 - RTO-K18 - Spectrum Analysis
- RTO2033 - RTO-K19 - Zone Trigger
- RTO2033 - RTO-K21 - USB 2.0 Compliance Test
- RTO2033 - RTO-K22 - Ethernet Compliance Test (10/100/1000BASE-T)
- RTO2033 - RTO-K23 - Ethernet Compliance Test (10GBASE-T)
- RTO2033 - RTO-K24 - BroadR-Reach Compliance Test (100BASE-T1)
- RTO2033 - RTO-K25 - Ethernet Compliance Test (2.5G/5G-BASE-T)
- RTO2033 - RTO-K26 - MIPI D-PHY Compliance Test
- RTO2033 - RTO-K31 - Power Analysis
- RTO2033 - RTO-K40 - MIPI RFFE Serial Triggering and Decoding
- RTO2033 - RTO-K42 - MIPI D-PHY Serial Triggering and Decoding
- RTO2033 - RTO-K44 - MIPI M-PHY Serial Triggering and Decoding
- RTO2033 - RTO-K50 - Manchester and NRZ Serial Triggering and Decoding
- RTO2033 - RTO-K52 - 8b10b Serial Decoding
- RTO2033 - RTO-K55 - MDIO Serial Triggering and Decoding
- RTO2033 - RTO-K60 - USB 1.0/1.1/2.0/HSIC Serial Triggering and Decoding
- RTO2033 - RTO-K61 - USB 3.1 Gen 1 Serial Triggering and Decoding
- RTO2033 - RTO-K63 - USB Power Delivery Serial Triggering and Decoding
- RTO2033 - RTO-K65 - SpaceWire Serial Triggering and Decoding
- RTO2033 - RTO-K72 - PCI Express 1.1/2.0 Serial Triggering and Decoding
- RTO2033 - RTO-K76 - CXPI Serial Triggering and Decoding
- RTO2033 - RTO-K81 - PCI Express 1.1/2.0 Compliance Test
- RTO2033 - RTO-K86 - Energy-Efficient Ethernet Compliance Test (10M/100M/1G-BASE-T)
- RTO2033 - RTO-K87 - 1000BASE-T1 Compliance Test
- RTO2033 - RTO-K92 - eMMC Compliance Test
| Model | RTO2033 |
|---|
The Rohde and Schwarz RTO2033 is a high-performance digital oscilloscope offering bandwidths from 600 MHz to 4 GHz, with configurations of 2 or 4 channels. It provides up to 16-bit vertical resolution and a fast acquisition rate of 1,000,000 waveforms per second, ensuring detailed signal analysis and precision measurements.
Engineered for high-speed data capture, the RTO2033 supports sampling rates up to 20 Gsample/s, making it ideal for advanced testing, debugging, and verification applications in demanding environments.
Testwall can supply the used Rohde and Schwarz RTO2033, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde and Schwarz RTO2033.
