Rohde & Schwarz SMZ75
Frequency Multiplier, 50 GHz to 75 GHz
60 GHz to 90 GHz Frequency Range
W-Band Frequency Band
-10 dBm at 75 GHz Output Power (typical)
10 GHz to 15 GHz Input Frequency Range
x6 Multiplication Factor
| Attribute | Value |
|---|---|
| Frequency Range | 60 GHz to 90 GHz |
| Frequency Band | W-Band |
| Output Power (typical) | -10 dBm at 75 GHz |
| Input Frequency Range | 10 GHz to 15 GHz |
| Multiplication Factor | x6 |
| RF Connector Type | WR-12 Waveguide |
| Input Connector | 2.4 mm coaxial (female) |
| Compatible Signal Generators | Rohde & Schwarz SMF100A, SMB100A, SMA100B and similar R&S signal generators |
| Operating Temperature Range | +5 °C to +45 °C |
| Dimensions (W x H x D) | Compact external millimeter-wave head module, approximately 100 mm x 50 mm x 30 mm |
Rohde & Schwarz SMZ75 Options:
- SMZ75 - SMZ-B75M - Mechanically Controlled Attenuator for the R&S SMZ75
- SMZ75 - SMZ-B75E - Electronically Controlled Attenuator for the R&S SMZ75
- SMZ75 - SMZ-K1 - Software License for external PC software
| Model | SMZ75 |
|---|
The Rohde and Schwarz SMZ75 operates across 50 GHz to 170 GHz, offering wide frequency and dynamic ranges with exceptional signal quality. It’s engineered for seamless integration with advanced test systems, delivering precise output levels in high-frequency environments.
Ideal for automotive radar, astronomy, and radar interferometry, the SMZ75 ensures easy handling and consistently high performance across various technical applications.
Testwall can supply the used Rohde and Schwarz SMZ75, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde and Schwarz SMZ75.
