Rohde & Schwarz ESIB26
| Attribute | Value |
|---|---|
| Frequency Range | 20 Hz – 26.5 GHz |
| Resolution Bandwidth | 10 Hz – 10 MHz |
| Display Range | 100 dB |
| Displayed Average Noise Level (DANL) | -150 dBm (typical, at 1 GHz) |
| Phase Noise | -113 dBc/Hz at 10 kHz offset (at 1 GHz) |
| Input Impedance | 50 Ohm |
| Maximum Input Level | +30 dBm (1 W) |
| Spurious Free Dynamic Range | 70 dB (typical) |
| Measurement Functions | EMI measurements, spectrum analysis, signal analysis, level measurements |
| Interface / Connectivity | GPIB (IEEE 488), RS-232, parallel port |
Rohde & Schwarz ESIB26 Options:
- ESIB26 - ESIB-B2 - Preamplifier 20 dB, 7 GHz to 26.5 GHz
- ESIB26 - FSE-B7 - Vector Signal Analyzer
- ESIB26 - FSE-B10 - Tracking Generator 7 GHz
- ESIB26 - FSE-B11 - Tracking Generator 7 GHz with I/Q Modulator
- ESIB26 - FSE-B12 - Switchable Attenuator for Tracking Generator
- ESIB26 - FSE-B16 - Ethernet Card, RJ-45 connector
- ESIB26 - FSE-B17 - Second IEC/IEEE-bus Card
- ESIB26 - FSE-B18 - Removable Hard Disk for ESIB
- ESIB26 - FSE-B19 - Second Hard Disk for ESIB, WindowsNT
- ESIB26 - FSE-B21 - External mixer output for ESIB26/40
- ESIB26 - EMC32-E - EMC Measurement Software (32 bit)
- ESIB26 - ES-K1 - EMI Software for EMI Test Receiver (Windows)
- ESIB26 - ES-K2 - Script Development Kit
- ESIB26 - ES-K16 - Driver for ESIB7/26/40
- ESIB26 - ES-K30 - Driver for Mast (Schäfer) and Turntable (Schäfer)
- ESIB26 - ES-K31 - Driver for MDS Absorbing Clamp Slideway (Schäfer)
| Model | ESIB26 |
|---|
The Rohde & Schwarz ESIB26 offers high sensitivity and low inherent noise, enabling precise signal detection across a wide dynamic range. Featuring fast measurement speeds, integrated preselection and preamplification, it includes dual RF inputs with pulse protection. The device adheres to commercial and military standards like CISPR, EN, FCC, VDE, MIL-STD, and more.
Ideal for EMI testing, the ESIB26 supports automatic overload detection, autoranging, and detailed pulse analysis using split-screen and analog level displays. Conforms to CISPR 16-1-1 and VDE 0876 for pulse weighting.
Testwall can supply the used Rohde & Schwarz ESIB26, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde & Schwarz ESIB26.
