Solar 9354-1 Options:
- 9354-1 - 9554-( ) - Variable Frequency Modules: provide tunable frequencies for injection of damped sinusoidal waveforms from 10 kHz to 100 MHz
- 9354-1 - 9335-2 - Solar Type 9335-2 Multiple Impedance Coupling Clamp: inductive injection device providing voltage and current transfer of 1:1, 1:1.5 and 1:3 voltage step-up and 2:1 voltage step-down; recommended for cable current injection from 10 kHz to 1 MHz
- 9354-1 - 2925-1 - Solar Type 2925-1 Calibration Fixture: 50 Ω calibration fixture based on dimensions of Type 9335-2 Coupling Clamp, maintains low SWR from 10 kHz to 100 MHz
- 9354-1 - 9142-1N - Solar Type 9142-1N Injection Probe: recommended for cable current injection from 10 MHz to 100 MHz
- 9354-1 - 9125-1 - Solar Type 9125-1 Calibration Fixture: calibration fixture for use with Type 9142-1N Injection Probe
- 9354-1 - 9123-1N - Solar Type 9123-1N Current Probe: used to monitor injected pulses of the 10 MHz, 30 MHz and 100 MHz outputs
- 9354-1 - 9410-1 - Solar Type 9410-1 (50 Ω / 50 Ω) High Voltage Attenuator: provides 40 dB attenuation from 10 kHz to 100 MHz; protects oscilloscope from high voltage damage when verifying output pulses
- 9354-1 - 9454-1 - Solar Type 9454-1 (600 Ω / 50 Ω) High Voltage Attenuator: provides 40 dB attenuation from 10 kHz to 100 MHz; provides high impedance to generator for measuring open circuit output pulses
- 9354-1 - 6220-4 - Solar Type 6220-4 High Voltage Audio Isolation Transformer: provides twice the open circuit voltage or twice the short circuit current for 10 kHz and 100 kHz damped sinusoid waves and 70 µS double exponential pulse; capable of handling up to 4000 V
- 9354-1 - 9616-1 - Solar Type 9616-1 Injection Clamp: provides coupling for high voltage pulses produced by Models 9354-1 and 9354-2
| Model | 9354-1 |
|---|
The Solar 9354-1 is a precision transient limiter engineered to safeguard EMI receivers and spectrum analyzers from damaging conducted disturbances during compliance testing. Designed for use with LISNs, it ensures accurate measurements by minimizing insertion loss while providing rugged and durable performance. Its compact design allows seamless integration into EMC test setups.
Widely adopted in EMC laboratories, the Solar 9354-1 offers reliable protection during conducted emissions testing, enabling compliance with international standards. It is built for continuous operation in demanding environments while ensuring test efficiency.
Testwall can supply the used Solar 9354-1, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Solar 9354-1.
