Rohde & Schwarz FSH6-06 6GHz Portable Spectrum Analyzer, Type N (f)
| Attribute | Value |
|---|---|
| Frequency Range | 100 kHz to 6 GHz |
| Connector Type | Type N (female) |
| Display | 6.5-inch color TFT LCD touchscreen, 640 x 480 pixels |
| Dynamic Range | >95 dB |
| Resolution Bandwidth (RBW) | 100 Hz to 3 MHz |
| Phase Noise | <-100 dBc/Hz at 10 kHz offset (typical) |
| DANL (Displayed Average Noise Level) | -161 dBm (typical, with preamplifier) |
| Battery Life | Up to 3.5 hours with internal Li-ion battery pack |
| Interfaces | USB, LAN (Ethernet), SD card slot |
| Weight | Approximately 2.9 kg (6.4 lbs) including battery |
Rohde & Schwarz FSH6-06 6GHz Portable Spectrum Analyzer, Type N (f) Options:
- FSH6-06 - FSH-B1 - Distance-to-Fault Measurement (includes 1 m cable, FSH-Z2 required)
- FSH6-06 - FSH-K1 - Remote Control via RS-232-C
- FSH6-06 - FSH-K2 - Vector Transmission and Reflection Measurements
- FSH6-06 - FSH-K3 - Receiver Mode
| Model | FSH6-06 |
|---|
The Rohde & Schwarz FSH6/06 is a robust portable spectrum analyzer with a frequency range from 100 kHz to 6 GHz, supporting resolution bandwidths from 100 Hz to 1 MHz and a noise floor of -135 dBm. It offers excellent amplitude accuracy under 1.5 dB, typical 0.5 dB, with an input dynamic range from –80 dBm to +20 dBm, and a high-resolution 14 cm color LCD. It includes a power sensor connector, RS-232 interface, and a 4-hour battery life.
Ideal for on-site RF analysis, the unit supports PC software connectivity, audio output via a 3.5 mm jack, and stores up to 256 traces in internal memory. The N-type 50 Ω connector ensures signal integrity.
Testwall can supply the used Rohde & Schwarz FSH6/06 6GHz Portable Spectrum Analyzer, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde & Schwarz FSH6/06 6GHz Portable Spectrum Analyzer.
