Rohde & Schwarz RTO1022 Digital Oscilloscope
| Attribute | Value |
|---|---|
| Bandwidth | 200 MHz |
| Number of Channels | 2 |
| Sample Rate | 5 Gsample/s |
| Record Length | 20 Msample (standard), up to 400 Msample (optional) |
| Vertical Resolution | 8 bit (up to 16 bit with high resolution mode) |
| Display | 10.4-inch capacitive touchscreen, 1024 x 768 resolution |
| Waveform Update Rate | Up to 1,000,000 waveforms/second |
| Input Impedance | 1 MΩ || 18 pF / 50 Ω |
| Time Base Range | 25 ps/div to 10,000 s/div |
| Connectivity / Interfaces | USB, LAN (Ethernet), GPIB (optional), DVI display output |
Rohde & Schwarz RTO1022 Digital Oscilloscope Options:
- RTO1022 - RTO-B1 - Mixed Signal Option, 400 MHz (additional 16 logic channels)
- RTO1022 - RTO-B4 - OCXO 10 MHz (precision reference frequency with reference input and output connectors)
- RTO1022 - RTO-B10 - GPIB Interface
- RTO1022 - RTO-B18 - Solid State Disk
- RTO1022 - RTO-B19 - Additional Removable Hard Disk
- RTO1022 - RTO-B101 - Memory Upgrade, 50 Msample per channel
- RTO1022 - RTO-B102 - Memory Upgrade, 100 Msample per channel
- RTO1022 - RTO-B103 - Memory Upgrade, 200 Msample per channel (instruments with operating system Windows 7 embedded)
- RTO1022 - RTO-B104 - Memory Upgrade, 400 Msample per channel (instruments with operating system Windows 7 embedded)
- RTO1022 - RTO-B200 - Upgrade to 1 GHz bandwidth, incl. calibration
- RTO1022 - RTO-B201 - Upgrade to 2 GHz bandwidth, incl. calibration
- RTO1022 - RTO-U1 - Upgrade of operating system from Windows XP embedded to Windows 7 embedded
- RTO1022 - RTO-K1 - I2C/SPI Serial Decoding
- RTO1022 - RTO-K2 - UART/RS-232/RS-422/RS-485 Serial Decoding
- RTO1022 - RTO-K3 - CAN/LIN Serial Triggering and Decoding
- RTO1022 - RTO-K4 - FlexRay Serial Triggering and Decoding
- RTO1022 - RTO-K5 - I2S Serial Triggering and Decoding
- RTO1022 - RTO-K6 - MIL-STD-1553 Serial Triggering and Decoding
- RTO1022 - RTO-K7 - ARINC 429 Serial Triggering and Decoding
- RTO1022 - RTO-K8 - Ethernet Serial Decoding
- RTO1022 - RTO-K9 - CAN FD Serial Triggering and Decoding
- RTO1022 - RTO-K11 - I/Q Software Interface
- RTO1022 - RTO-K12 - Jitter Analysis
- RTO1022 - RTO-K13 - Realtime Clock Data Recovery (CDR)
- RTO1022 - RTO-K17 - High Definition Mode
- RTO1022 - RTO-K21 - USB 2.0 Compliance Test
- RTO1022 - RTO-K22 - Ethernet Compliance Test
- RTO1022 - RTO-K23 - Ethernet 10G Compliance Test
- RTO1022 - RTO-K24 - BroadR-Reach Compliance Test
- RTO1022 - RTO-K26 - D-PHY Compliance Test
- RTO1022 - RTO-K31 - Power Analysis
- RTO1022 - RTO-K40 - MIPI RFFE Serial Triggering and Decoding
- RTO1022 - RTO-K55 - MDIO Serial Triggering and Decoding
- RTO1022 - RTO-K60 - USB 1.0/1.1/2.0/HSIC Serial Triggering and Decoding
| Model | RTO1022 |
|---|
The Rohde & Schwarz RTO1022 is a 2-channel, 2GHz digital oscilloscope offering 10GS/s sampling rate, ultra-low noise input amplifiers, and over 7 effective bits dynamic range. It features the world's first realtime digital trigger system, enabling accurate and reliable signal fault detection.
Its high acquisition rate of one million waveforms per second and intuitive user interface make it ideal for precise diagnostics and fast signal analysis in complex environments.
Testwall can supply the used Rohde & Schwarz RTO1022, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde & Schwarz RTO1022.
