Rohde & Schwarz
Rohde & Schwarz RTO2014 Digital oscilloscope, 4 channels, 1GHz bandwidth, sampling rate 10GSa/s per channel, sampling memory 50MSa per channel
Digital oscilloscope,? 4 channels, 1GHz bandwidth, sampling rate 10GSa/s per channel,? sampling memory 50MSa per channel
1 GHz Bandwidth
4 Number of Channels
10 GSa/s per channel Sample Rate
50 MSa per channel Acquisition Memory
8-bit (up to 16-bit with High Definition mode) Vertical Resolution
| Attribute | Value |
|---|---|
| Bandwidth | 1 GHz |
| Number of Channels | 4 |
| Sample Rate | 10 GSa/s per channel |
| Acquisition Memory | 50 MSa per channel |
| Vertical Resolution | 8-bit (up to 16-bit with High Definition mode) |
| Rise Time | 350 ps |
| Display | 10.4-inch capacitive touchscreen, 1024 x 768 resolution |
| Input Impedance | 50 Ω / 1 MΩ selectable |
| Time Base Range | 25 ps/div to 10,000 s/div |
| Connectivity & Interfaces | USB, LAN (LXI), DisplayPort, optional GPIB |
| Model | RTO2014 |
|---|
The Rohde & Schwarz RTO2014 is a 4-channel, 1GHz digital oscilloscope with a 2Gsample deep memory, offering up to 16-bit vertical resolution and a 10GSa/s sampling rate per channel.
It features advanced debugging tools like multi-channel spectrum analysis, 1 million waveforms/s, and a high-resolution touchscreen with gesture support and SmartGrid customization.
Testwall can supply the used Rohde & Schwarz RTO2014 Digital Oscilloscope, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde & Schwarz RTO2014 Digital Oscilloscope.
