Rohde & Schwarz RTO2022 Digital Oscilloscope
| Attribute | Value |
|---|---|
| Bandwidth | 2 GHz |
| Number of Channels | 2 |
| Sample Rate | 10 Gsample/s |
| Vertical Resolution | 8 bit (up to 16 bit with HD mode) |
| Memory Depth | 50 Mpoints per channel (standard), up to 2 Gpoints (optional) |
| Display | 12.1-inch capacitive touchscreen, 1280 x 800 resolution |
| Input Impedance | 50 Ω / 1 MΩ selectable |
| Time Base Range | 25 ps/div to 10000 s/div |
| Waveform Update Rate | Up to 1,000,000 waveforms per second |
| Connectivity / Interfaces | USB, LAN (LXI), DisplayPort, optional GPIB |
Rohde & Schwarz RTO2022 Digital Oscilloscope Options:
- RTO2022 - RTO-B1 - Mixed Signal Option, 400 MHz (additional 16 logic channels)
- RTO2022 - RTO-B4 - OCXO 10 MHz (precision reference frequency with reference input and output connectors)
- RTO2022 - RTO-B10 - GPIB Interface
- RTO2022 - RTO-B19 - Additional Solid State Disk
- RTO2022 - RTO-B101 - Memory Upgrade, 100 Msample per channel
- RTO2022 - RTO-B102 - Memory Upgrade, 200 Msample per channel
- RTO2022 - RTO-B104 - Memory Upgrade, 400 Msample per channel
- RTO2022 - RTO-B110 - Memory Upgrade, 1 Gsample per channel
- RTO2022 - RTO-B202 - Upgrade of RTO2022 to 2 GHz bandwidth
- RTO2022 - RTO-B203 - Upgrade of RTO2022 to 3 GHz bandwidth
- RTO2022 - RTO-B224 - Upgrade of RTO2022/4 to 4 GHz bandwidth
- RTO2022 - RTO-K1 - I2C/SPI Serial Decoding
- RTO2022 - RTO-K2 - UART/RS-232/RS-422/RS-485 Serial Decoding
- RTO2022 - RTO-K3 - CAN/LIN Serial Triggering and Decoding
- RTO2022 - RTO-K4 - FlexRay Serial Triggering and Decoding
- RTO2022 - RTO-K5 - I2S Serial Triggering and Decoding
- RTO2022 - RTO-K6 - MIL-STD-1553 Serial Triggering and Decoding
- RTO2022 - RTO-K7 - ARINC 429 Serial Triggering and Decoding
- RTO2022 - RTO-K8 - Ethernet Serial Decoding
- RTO2022 - RTO-K9 - CAN-FD Serial Triggering and Decoding
- RTO2022 - RTO-K10 - SENT Serial Triggering and Decoding
- RTO2022 - RTO-K11 - I/Q Software Interface
- RTO2022 - RTO-K12 - Jitter Analysis
- RTO2022 - RTO-K13 - Clock Data Recovery
- RTO2022 - RTO-K17 - High Definition Mode
- RTO2022 - RTO-K19 - Zone Trigger
- RTO2022 - RTO-K22 - Ethernet Compliance Test
- RTO2022 - RTO-K31 - Power Analysis
- RTO2022 - RTO-K40 - MIPI RFFE Serial Triggering and Decoding
- RTO2022 - RTO-K42 - MIPI D-PHY Serial Triggering and Decoding
- RTO2022 - RTO-K50 - Manchester and NRZ Serial Triggering and Decoding
- RTO2022 - RTO-K52 - 8b10b Serial Decoding
- RTO2022 - RTO-K55 - MDIO Serial Triggering and Decoding
- RTO2022 - RTO-K60 - USB 1.0/1.1/2.0/HSIC Serial Triggering and Decoding
- RTO2022 - RTO-K65 - SpaceWire Serial Triggering and Decoding
| Model | RTO2022 |
|---|
The Rohde & Schwarz RTO2022 is a high-performance digital oscilloscope offering 2 channels, 2 GHz bandwidth, and an impressive 10 GSa/s sampling rate per channel. With a maximum memory depth of 2 GSa and vertical resolution up to 16 bits, it delivers precise signal fidelity. The optional RTO-B1 MSO upgrade adds 16 digital channels for advanced mixed-signal debugging. Its ultra-low noise architecture ensures accurate measurements, ideal for demanding high-speed applications.
It comes equipped with two 500 MHz passive voltage probes and supports deep memory and high-resolution acquisition, making it suitable for debugging and analysis of high-speed digital, RF, and power signals.
Testwall can supply the used Rohde & Schwarz RTO2022 Digital Oscilloscope, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde & Schwarz RTO2022 Digital Oscilloscope.
