Rohde & Schwarz
Rohde & Schwarz SMB100A-B103
3.2 GHz Analog Signal Generator
100 kHz to 3.2 GHz Frequency Range
Frequency Extension Option (B103) Option Type
-145 dBm to +18 dBm (typical) Output Power Range
0.001 Hz Frequency Resolution
-134 dBc/Hz at 1 GHz, 20 kHz offset (typical) Phase Noise
€6,900.00 excl. VAT + free EU delivery
| Attribute | Value |
|---|---|
| Frequency Range | 100 kHz to 3.2 GHz |
| Option Type | Frequency Extension Option (B103) |
| Output Power Range | -145 dBm to +18 dBm (typical) |
| Frequency Resolution | 0.001 Hz |
| Phase Noise | -134 dBc/Hz at 1 GHz, 20 kHz offset (typical) |
| Modulation Types | AM, FM, PhiM, Pulse Modulation |
| RF Output Connector | N-type female, 50 Ohm |
| Reference Frequency | 10 MHz internal/external reference |
| Power Supply | 100 V to 240 V AC, 50 Hz to 60 Hz |
| Interface/Connectivity | USB, LAN (LXI), GPIB (optional) |
Rohde & Schwarz SMB100A-B103 Options:
- SMB100A-B103 - SMB-B101 - RF Path 9 kHz to 1.1 GHz
- SMB100A-B103 - SMB-B102 - RF Path 9 kHz to 2.2 GHz
- SMB100A-B103 - SMB-B103 - RF Path 9 kHz to 3.2 GHz
- SMB100A-B103 - SMB-B106 - RF Path 9 kHz to 6 GHz
- SMB100A-B103 - SMB-B1 - Reference Oscillator OCXO
- SMB100A-B103 - SMB-B5 - Stereo/RDS Coder
- SMB100A-B103 - SMB-K22 - Pulse Modulator
- SMB100A-B103 - SMB-K23 - Pulse Generator
| Model | SMB100A-B103 |
|---|
The Rohde & Schwarz SMB100A/B103 is a high-quality signal generator covering a frequency range from 9 kHz to 3.2 GHz. It delivers excellent performance with an SSB phase noise of less than -128 dBc/Hz at 1 GHz with a 20 kHz offset.
It supports AM, FM, and phase modulation as standard, with optional pulse modulation, and achieves high output power up to +25 dBm with overrange.
Testwall can supply the used Rohde & Schwarz SMB100A/B103, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde & Schwarz SMB100A/B103.
