Rohde & Schwarz URV5-Z4
| Attribute | Value |
|---|---|
| Frequency Range | DC to 6 GHz |
| Power Measurement Range | -67 dBm to +20 dBm |
| Connector Type | N-type (50 Ω) |
| Impedance | 50 Ω |
| SWR (Standing Wave Ratio) | ≤ 1.15 (up to 2 GHz), ≤ 1.25 (up to 6 GHz) |
| Sensor Type | Diode-based RF power sensor |
| Compatible Instrument | Rohde & Schwarz URV5 Voltmeter/Power Meter |
| Maximum Input Power (Continuous) | 200 mW (+23 dBm) |
| Operating Temperature Range | 0 °C to +55 °C |
| Measurement Uncertainty | ± 0.5 dB (typical, within calibrated range) |
| Model | URV5-Z4 |
|---|
The Rohde & Schwarz URV5-Z4 is a high-performance 100V Insertion Unit designed for 50 Ohm systems. With its precision engineering, the unit provides exceptional accuracy in measurements and is essential for integration in test setups that require high-voltage performance. The URV5-Z4 is optimized for a broad range of RF applications.
This insertion unit is ideal for use in RF test environments, ensuring reliable insertion of signals with minimal interference. It is built to meet the high demands of professional engineers and researchers in the field of RF and communications.
Testwall can supply the used Rohde & Schwarz URV5-Z4 100V Insertion Unit 50 Ohm, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde & Schwarz URV5-Z4.
