Rohde & Schwarz ZVC62
| Attribute | Value |
|---|---|
| Frequency Range | 10 MHz to 62.4 GHz |
| Number of Test Ports | 2 |
| Dynamic Range | Up to 117 dB |
| Output Power Range | -30 dBm to +3 dBm |
| Measurement Parameters | S-parameters, impedance, admittance, stability factors, group delay |
| Connector Type | 1.85 mm (V-connector) |
| IF Bandwidth | 1 Hz to 100 kHz |
| Trace Noise | <0.004 dB RMS at 10 Hz IF bandwidth |
| Display | 10.4-inch color TFT LCD touchscreen |
| Interface/Connectivity | GPIB, USB, LAN (Ethernet) |
Rohde & Schwarz ZVC62 Options:
- ZVC62 - ZVR-B1 - Automatic Calibration AutoKal (0 Hz to 8 GHz)
- ZVC62 - ZVR-B2 - Time Domain
- ZVC62 - ZVR-B4 - Mixer Measurements (includes harmonics measurements)
- ZVC62 - ZVR-B5 - Nonlinear Measurements
- ZVC62 - ZVR-B6 - Reference Channel Ports
- ZVC62 - ZVR-B7 - Power Calibration (power meter and sensor required)
- ZVC62 - ZVR-B8 - 3-Port Adapter (up to 4 GHz)
- ZVC62 - ZVR-K9 - Virtual Embedding Networks
- ZVC62 - ZVR-B10 - Increased Output Power for Port 1 or Output a1
- ZVC62 - ZVR-B14 - 4-Port Adapter (2 x SPDT) (up to 4 GHz)
- ZVC62 - ZVR-B14 - 4-Port Adapter (SP3T) (up to 4 GHz)
- ZVC62 - FSE-B16 - Ethernet RJ 45 for Internal PC
- ZVC62 - FSE-B17 - IEC/IEEE Bus Interface for Internal PC
- ZVC62 - ZVR-B21 - Generator Step Attenuator PORT 1
- ZVC62 - ZVR-B22 - Generator Step Attenuator PORT 2
- ZVC62 - ZVR-B23 - Receiver Step Attenuator PORT 1
- ZVC62 - ZVR-B24 - Receiver Step Attenuator PORT 2
- ZVC62 - ZVR-B25 - External Measurements, 50 Ω (20 kHz to 8 GHz)
- ZVC62 - ZVR-Z1 - Service Kit
| Model | ZVC62 |
|---|
The R&S ZVC 8 GHz Network Analyzer includes a built-in test set with active SWR Bridges, an electronic RF switch, two measurement channels and two reference channels. The ZVC62 specifies it as: 4 Channel, bi-directional, 50 Ohm, Active SWR Bridge. With this config, a variety of unique calibration procedures, eg., TNA, can be performed, which drastically improve the accuracy, particularly in non-coaxial applications. This unit is suitable for applications in R&D and production no matter how sophisticated. It is always equipped with 50 W active test sets. Additional step attenuators, 0 dB to 70 dB, can be inserted into the generator paths and the two measurement channels to extend the power range of the receivers to +27 dBm and to lower minimum output power to -95 dBm. When the test set is fitted with attenuators and the External Measurements option, generator and receiver can be alternatively switched to three ports on the front panel (OUTPUT a1, INPUT b1, INPUT b2). This increases output power, sensitivity and dynamic range. In addition, the flexibility on external test sets, e.g. using an external pre-amplifier, is enhanced. The Reference Channel Ports allow to feed the signal for the reference channel a1 from outside. This feature facilitates phase measurements on frequency converting devices. The test ports are fitted with female N connectors.
Other Key Facts: Excellent dynamic range >130 dB (IF bandwidth 10 Hz) Low inhe noise 25 sweeps/s (200 points) Manual calibration techniques TOM, TRM, TRL, TNA, TOM-X, TOSM Automatic calibration AutoKal Compatibility with PC, CAE Internal PC with Windows NT operating system suitable for PC applications.
