Sorensen
Sorensen DCR150-11B
150V-11A DC Power Supply
0 – 150 VDC Output Voltage
0 – 11 A Output Current
1650 W Output Power
115/230 VAC, Single Phase, 47–63 Hz Input Voltage
0.01% + 2 mV Line Regulation (Voltage)
| Attribute | Value |
|---|---|
| Output Voltage | 0 – 150 VDC |
| Output Current | 0 – 11 A |
| Output Power | 1650 W |
| Input Voltage | 115/230 VAC, Single Phase, 47–63 Hz |
| Line Regulation (Voltage) | 0.01% + 2 mV |
| Load Regulation (Voltage) | 0.01% + 2 mV |
| Ripple and Noise (RMS) | 1 mV RMS |
| Programming Interface | Analog (0–5 V or 0–10 V), Resistance |
| Operating Temperature | 0°C to 50°C |
| Cooling Method | Fan Cooled |
Sorensen DCR150-11B Options:
- DCR150-11B - M1 - 208 Vac ± 10% input voltage
- DCR150-11B - M2 - 220 Vac ± 10% input voltage
- DCR150-11B - M3 - 230 Vac ± 10% input voltage
- DCR150-11B - M35 - Polarity & load disconnect
- DCR150-11B - M50 - LCD digital meters
| Model | DCR150-11B |
|---|
0 to 150 V, 0 to 11 A, DC Power Supply
