Sorensen
Sorensen DCR32-315T
32-315A DC Power Supply
0 - 32 VDC Output Voltage
0 - 315 A Output Current
10,080 W (10.08 kW) Output Power
208/240 VAC, 3-Phase Input Voltage
47 - 63 Hz Input Frequency
| Attribute | Value |
|---|---|
| Output Voltage | 0 - 32 VDC |
| Output Current | 0 - 315 A |
| Output Power | 10,080 W (10.08 kW) |
| Input Voltage | 208/240 VAC, 3-Phase |
| Input Frequency | 47 - 63 Hz |
| Line Regulation | 0.02% of full scale output |
| Load Regulation | 0.05% of full scale output |
| Ripple and Noise (RMS) | 15 mV RMS / 75 mV peak-to-peak |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Cooling Method | Forced air cooling (internal fans) |
Sorensen DCR32-315T Options:
- DCR32-315T - T1 - 208V, 60Hz, STD. U.S. Voltage
- DCR32-315T - T2 - 380V, 50Hz, STD. Continental Europe Voltage
- DCR32-315T - T3 - 415V, 50Hz, STD. British Isles Voltage
- DCR32-315T - T4 - 440V, 60Hz, STD. U.S. Voltage
- DCR32-315T - T5 - 480V, 60Hz, STD. U.S. Voltage
- DCR32-315T - 1060247-1 - Chassis Slides
- DCR32-315T - 488 MICRO DAP - Interface to GPIB Bus (Digital Programmer)
- DCR32-315T - M5 - SCR Crowbar OVP Option
- DCR32-315T - M52 - Analog Metering
| Model | DCR32-315T |
|---|
