Sorensen
Sorensen DCR600-3B2
Power Supply, 600V, 3A, 1800W
0 - 600 VDC Output Voltage
0 - 3 A Output Current
1800 W Output Power
208/240 VAC, Single Phase Input Voltage
47 - 63 Hz Input Frequency
| Attribute | Value |
|---|---|
| Output Voltage | 0 - 600 VDC |
| Output Current | 0 - 3 A |
| Output Power | 1800 W |
| Input Voltage | 208/240 VAC, Single Phase |
| Input Frequency | 47 - 63 Hz |
| Line Regulation | 0.01% + 2 mV |
| Load Regulation | 0.01% + 2 mV |
| Ripple and Noise | 15 mV RMS / 75 mV Peak-to-Peak |
| Programming Interface | Analog (0-5V or 0-10V), Isolated |
| Operating Temperature | 0°C to 50°C |
Sorensen DCR600-3B2 Options:
- DCR600-3B2 - M1 - 208 Vac ± 10% input voltage
- DCR600-3B2 - M2 - 220 Vac ± 10% input voltage
- DCR600-3B2 - M3 - 230 Vac ± 10% input voltage
- DCR600-3B2 - M35 - Polarity & load disconnect
- DCR600-3B2 - M50 - LCD digital meters
| Model | DCR600-3B2 |
|---|
