Sorensen
Sorensen DCR600-6B
600-6A DC Power Supply
600 VDC Output Voltage
6 A Output Current
3600 W Output Power
208/240 VAC, Single Phase Input Voltage
47–63 Hz Input Frequency
| Attribute | Value |
|---|---|
| Output Voltage | 600 VDC |
| Output Current | 6 A |
| Output Power | 3600 W |
| Input Voltage | 208/240 VAC, Single Phase |
| Input Frequency | 47–63 Hz |
| Line Regulation | 0.01% of full scale output |
| Load Regulation | 0.01% of full scale output |
| Ripple and Noise (RMS) | 0.05% of full scale output |
| Operating Temperature | 0°C to 50°C |
| Cooling Method | Forced Air Cooling |
Sorensen DCR600-6B Options:
- DCR600-6B - M1 - 208 Vac ±10% input voltage
- DCR600-6B - M2 - 220 Vac ±10% input voltage
- DCR600-6B - M3 - 230 Vac ±10% input voltage
- DCR600-6B - M35 - Polarity & load disconnect
- DCR600-6B - M50 - LCD digital meters
| Model | DCR600-6B |
|---|
The Sorensen DCR600-6B is a 600 Volt, 6 Amp DC Power Supply.
