Sorensen
Sorensen DCS20-150E
20-150A DC Power Supply
0 – 20 VDC Output Voltage
0 – 150 A Output Current
3000 W Output Power
105–132 VAC / 210–264 VAC, Single Phase, 47–63 Hz Input Voltage
0.01% + 2 mV Line Regulation (Voltage)
| Attribute | Value |
|---|---|
| Output Voltage | 0 – 20 VDC |
| Output Current | 0 – 150 A |
| Output Power | 3000 W |
| Input Voltage | 105–132 VAC / 210–264 VAC, Single Phase, 47–63 Hz |
| Line Regulation (Voltage) | 0.01% + 2 mV |
| Load Regulation (Voltage) | 0.01% + 2 mV |
| Ripple and Noise (RMS) | 10 mV RMS / 50 mV peak-to-peak |
| Programming Interface | 0–5 VDC or 0–10 VDC analog, RS-232/RS-485 optional |
| Operating Temperature | 0°C to 50°C |
| Dimensions (H x W x D) | 3.5 in x 19 in x 24 in (2U Rack Mount) |
| Model | DCS20-150E |
|---|
