Sorensen
Sorensen DCS55-55
55V 55A 2.8KW Single Channel DC Power supply
0 - 55 VDC Output Voltage
0 - 55 A Output Current
3025 W Output Power
208/240 VAC, Single Phase Input Voltage
47 - 63 Hz Input Frequency
| Attribute | Value |
|---|---|
| Output Voltage | 0 - 55 VDC |
| Output Current | 0 - 55 A |
| Output Power | 3025 W |
| Input Voltage | 208/240 VAC, Single Phase |
| Input Frequency | 47 - 63 Hz |
| Line Regulation | 0.01% + 2 mV (Voltage), 0.01% + 2 mA (Current) |
| Load Regulation | 0.01% + 2 mV (Voltage), 0.01% + 2 mA (Current) |
| Ripple and Noise | 1 mV RMS / 5 mV Peak-to-Peak (Voltage), 5 mA RMS (Current) |
| Operating Temperature | 0°C to 50°C |
| Form Factor | Rack Mount, 3U |
| Model | DCS55-55 |
|---|
The Sorensen DCS55-55 Power Supply, is a single output power supply with a voltage range of 0 V to 55 V DC with a maximum power of 3000 Watts.
