Sorensen
Sorensen DHP 20
0-75 200.0V Power Supply
0 – 20 V DC Output Voltage Range
0 – 100 A Output Current Range
2000 W (2 kW) Output Power
115/230 V AC, Single Phase, 50/60 Hz Input Voltage
0.01% + 2 mV Line Regulation (Voltage)
| Attribute | Value |
|---|---|
| Output Voltage Range | 0 – 20 V DC |
| Output Current Range | 0 – 100 A |
| Output Power | 2000 W (2 kW) |
| Input Voltage | 115/230 V AC, Single Phase, 50/60 Hz |
| Line Regulation (Voltage) | 0.01% + 2 mV |
| Load Regulation (Voltage) | 0.01% + 2 mV |
| Ripple and Noise (Voltage, rms) | 1 mV rms |
| Programming Accuracy (Voltage) | 0.1% + 10 mV |
| Operating Temperature Range | 0°C to 50°C |
| Cooling Method | Fan Cooled |
Sorensen DHP 20 Options:
- DHP - M1 - 360-440 VAC, 47-63 Hz, three phase, 3-wire plus ground, Delta or Wye may be used
- DHP - M2 - 432-528 VAC, 47-63 Hz, three phase, 3-wire plus ground, Delta or Wye may be used
- DHP - M8 - Internal RS-232 remote serial interface
- DHP - M9D - Internal IEEE-488.2 interface
- DHP - M10 - Both IEEE-488.2 and RS-232
- DHP - M11 - RS-232 and isolated analog programming
- DHP - M12 - IEEE-488.2 and isolated analog programming
- DHP - M14 - IEEE-488.2, RS-232 and isolated analog programming
- DHP - M51 - Isolated analog programming Input Voltage Options. This isolation allows users to control power supplies not connected to a common ground. In addition, in systems with high ambient noise or with large ground loop currents the control ground can be isolated from the power ground eliminating problems.
| Model | DHP |
|---|
