Sorensen
Sorensen DHP 8
0-62 80.0V Power Supply
0 – 600 V DC Output Voltage Range
0 – 16.7 A Output Current Range
5000 W (5 kW) Output Power
208/240 V AC, Single Phase Input Voltage
0.01% of full scale output Line Regulation
| Attribute | Value |
|---|---|
| Output Voltage Range | 0 – 600 V DC |
| Output Current Range | 0 – 16.7 A |
| Output Power | 5000 W (5 kW) |
| Input Voltage | 208/240 V AC, Single Phase |
| Line Regulation | 0.01% of full scale output |
| Load Regulation | 0.01% of full scale output |
| Ripple and Noise | 0.5% RMS of full scale output voltage |
| Programming Interface | Analog (0–5 V or 0–10 V), RS-232, GPIB (optional) |
| Operating Temperature | 0°C to 50°C |
| Cooling Method | Forced Air Cooling |
Sorensen DHP 8 Options:
- DHP - M1 - 360-440 VAC, 47-63 Hz, three phase, 3-wire plus ground, Delta or Wye may be used
- DHP - M2 - 432-528 VAC, 47-63 Hz, three phase, 3-wire plus ground, Delta or Wye may be used
- DHP - M8 - Internal RS-232 remote serial interface
- DHP - M9D - Internal IEEE-488.2 interface
- DHP - M10 - Both IEEE-488.2 and RS-232
- DHP - M11 - RS-232 and isolated analog programming
- DHP - M12 - IEEE-488.2 and isolated analog programming
- DHP - M14 - IEEE-488.2, RS-232 and isolated analog programming
- DHP - M51 - Isolated analog programming Input Voltage Options. This isolation allows users to control power supplies not connected to a common ground. In addition, in systems with high ambient noise or with large ground loop currents the control ground can be isolated from the power ground eliminating problems.
| Model | DHP |
|---|
