Sorensen
Sorensen LHP Serie
s - 1 kW 600.0V Power Supply
0 - 600 VDC Output Voltage Range
0 - 110 A Output Current Range
Up to 3300 W Output Power
105-132 VAC / 210-264 VAC, Single Phase Input Voltage
47 - 63 Hz Input Frequency
| Attribute | Value |
|---|---|
| Output Voltage Range | 0 - 600 VDC |
| Output Current Range | 0 - 110 A |
| Output Power | Up to 3300 W |
| Input Voltage | 105-132 VAC / 210-264 VAC, Single Phase |
| Input Frequency | 47 - 63 Hz |
| Line Regulation | 0.01% + 2 mV |
| Load Regulation | 0.01% + 2 mV |
| Ripple and Noise (RMS) | 1 mV RMS typical |
| Operating Temperature | 0°C to 50°C |
| Interface / Control | Analog programming, RS-232 optional |
Sorensen LHP Serie Options:
- LHP - M8 - Serial instrument programming using RS 232 protocol (May not be combined with M9B or M51)
- LHP - M9B - Full feature IEEE-488 programming with 14-bit resolution and software calibration (May not be combined with M8 or M51)
- LHP - M51 - Isolated analog programming of either voltage or current (May not be combined with M8 or M9B)
- LHP - RM2 - Rackmount kit
| Model | LHP |
|---|
