Sorensen
Sorensen XT250-0.25
Programmable DC Power Supply
0 - 250 VDC Output Voltage
0 - 0.25 A Output Current
62.5 W Output Power
100/120/220/240 VAC Input Voltage
47 - 63 Hz Input Frequency
| Attribute | Value |
|---|---|
| Output Voltage | 0 - 250 VDC |
| Output Current | 0 - 0.25 A |
| Output Power | 62.5 W |
| Input Voltage | 100/120/220/240 VAC |
| Input Frequency | 47 - 63 Hz |
| Line Regulation (Voltage) | 0.01% + 2 mV |
| Load Regulation (Voltage) | 0.01% + 2 mV |
| Ripple and Noise (RMS) | 1 mV RMS |
| Operating Temperature | 0°C to 50°C |
| Output Terminals | Binding Posts |
Sorensen XT250-0.25 Options:
- XT250-0.25 - M1 - Power Input Modification: 110V ±10%, 47-63 Hz
- XT250-0.25 - M2 - Power Input Modification: 220V ±10%, 47-63 Hz
- XT250-0.25 - M3 - Power Input Modification: 230V ±10%, 47-63 Hz
- XT250-0.25 - M4 - Power Input Modification: 240V ±10%, 47-63 Hz
- XT250-0.25 - M5A - Analog Programming: Internal interface for full scale remote programming of output voltage and/or current by a 0-10V or 0-10 kΩ external source; includes 0-10V readback, externally adjustable offset and range, front panel adjustable OVP, TTL shutdown with selectable logic, master/slave tracking and status signals
- XT250-0.25 - M9B - Internal IEEE-488 Interface: Complete remote programming including status reporting, settings query and interrupt generation with user designated fault conditions; voltage and current output precisely programmed directly in volts and amps (may not be combined with M5A)
- XT250-0.25 - M11 - 10-turn current control potentiometer
- XT250-0.25 - M13 - Locking shafts (front panel potentiometer)
- XT250-0.25 - RM-XHS - Rack Adapter Kit
| Model | XT250-0.25 |
|---|
