Stanford Research SG386
| Attribute | Value |
|---|---|
| Frequency Range | DC to 6.075 GHz |
| Frequency Resolution | 1 µHz |
| Output Power Range | -110 dBm to +16.5 dBm (Type N output); -110 dBm to +13 dBm (BNC output) |
| Phase Noise | -116 dBc/Hz at 1 kHz offset (1 GHz carrier) |
| Modulation Types | AM, FM, ØM (Phase), Pulse, I/Q modulation |
| Frequency Reference | Internal OCXO reference; external 10 MHz reference input supported |
| Output Impedance | 50 Ω |
| Harmonic Suppression | -30 dBc typical |
| Interface/Connectivity | GPIB, RS-232, Ethernet, USB |
| Power Requirements | 100–240 VAC, 50/60 Hz, 55 W maximum |
| Model | SG386 |
|---|
The Stanford Research (SRS) SG386 DC to 6GHz Analog Signal Generator offers exceptional frequency coverage from DC to 6.075 GHz with 1 Hz resolution, using Rational Approximation Frequency Synthesis for precise performance. It supports AM, FM, pulse modulation, sweeps, and features options such as frequency doubling to 8.10 GHz, low-jitter differential clock outputs, external I/Q modulation, and an optional rubidium timebase for demanding applications.
Designed for versatility, the SG386 is ideal for advanced RF testing, communications research, and signal simulation where high accuracy and low phase noise are critical.
Testwall can supply the used Stanford Research (SRS) SG386 DC to 6GHz Analog Signal Generator, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Stanford Research (SRS) SG386 DC to 6GHz Analog Signal Generator.
