Stanford Research
Stanford Research SIM911
0 - 1MHz PreAmplifier
4 nV/√Hz at 1 kHz Input Voltage Noise
1 to 100 (×1, ×2, ×5, ×10, ×20, ×50, ×100) Gain Range
DC to 10 MHz (gain ×1) Bandwidth
100 MΩ, 25 pF Input Impedance
AC or DC selectable Input Coupling
| Attribute | Value |
|---|---|
| Input Voltage Noise | 4 nV/√Hz at 1 kHz |
| Gain Range | 1 to 100 (×1, ×2, ×5, ×10, ×20, ×50, ×100) |
| Bandwidth | DC to 10 MHz (gain ×1) |
| Input Impedance | 100 MΩ, 25 pF |
| Input Coupling | AC or DC selectable |
| Output Voltage Range | ±10 V into 1 kΩ load |
| Power Requirements | Powered via SIM900 mainframe backplane |
| Input Configuration | Single-ended or differential (switchable) |
| Common Mode Rejection Ratio (CMRR) | 100 dB at 60 Hz |
| Form Factor | SIM module, fits SIM900 mainframe |
| Model | SIM911 |
|---|
The Stanford Research Systems SIM911 is a 0 - 1.0 MHz PreAmplifier
