Tektronix 1721
| Attribute | Value |
|---|---|
| Signal Format | NTSC Composite Video |
| Vectorscope Bandwidth | 5 MHz |
| Display Type | Internal CRT Display |
| Input Impedance | 75 Ohms |
| Input Connectors | BNC (A and B Inputs) |
| Power Requirements | 90–250 VAC, 45–440 Hz |
| Power Consumption | 45 Watts Maximum |
| Operating Temperature | 0°C to +50°C (32°F to 122°F) |
| Dimensions (H x W x D) | 133 mm x 212 mm x 368 mm (5.25 in x 8.3 in x 14.5 in) |
| Weight | Approximately 4.5 kg (10 lbs) |
| Model | 1721 |
|---|
The TEKTRONIX 1721 is an 8-1/2-inch wide, 5-1/4-inch high Vectorscope optimized for PAL systems (System I, B, etc.), and weighs 8-1/2 pounds. It features a CRT covering two-thirds of the front panel and a microprocessor-controlled momentary-touch switch interface with lighted indicators.
It can operate on AC power or 12 VDC with an optional field upgrade kit (1700F10), providing flexible usage in varied environments and seamless access to special functions through intelligent switch programming.
Testwall can supply the used TEKTRONIX 1721, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the TEKTRONIX 1721.
