Tektronix
Tektronix 370
Curve Tracer
High-resolution CRT display Display Type
3 A Maximum Collector Current
3000 V Maximum Collector Voltage
220 W Maximum Power Dissipation
Programmable DC Component Curve Tracer Curve Tracer Type
| Attribute | Value |
|---|---|
| Display Type | High-resolution CRT display |
| Maximum Collector Current | 3 A |
| Maximum Collector Voltage | 3000 V |
| Maximum Power Dissipation | 220 W |
| Curve Tracer Type | Programmable DC Component Curve Tracer |
| Step Generator Output | Voltage or Current steps, adjustable |
| Number of Steps | 1 to 10 steps |
| Sweep Voltage | 0 to 3000 V peak |
| Interface | IEEE-488 (GPIB) programmable interface |
| Power Requirements | 115/230 VAC, 50/60 Hz |
| Model | 370 |
|---|
The Tektronix 370 Curve Tracer provides precise testing and analysis of semiconductors and transistors with a 2,000V collector supply and 10A pulse current capability.
Equipped with high-resolution CRT display, dual cursor measurements, and safety interlocks, it ensures both accurate and secure operation.
Testwall can supply the used Tektronix 370, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix 370.
