Tektronix AWG5202
| Attribute | Value |
|---|---|
| Number of Channels | 2 |
| Sample Rate | Up to 5 GS/s |
| Vertical Resolution | 16-bit DAC |
| Analog Bandwidth | 2 GHz |
| Waveform Memory | Up to 2 GSamples per channel |
| Amplitude Range | 50 mVpp to 1 Vpp (into 50 Ω) |
| Marker Outputs | 2 markers per channel (4 total) |
| Sequence Depth | Up to 16,383 steps |
| Operating System | Windows 10 IoT Enterprise |
| Connectivity | USB, LAN (LXI), PCIe |
Tektronix AWG5202 Options:
- AWG5202 - AWG5200-225 - 2.5 GS/s
- AWG5202 - AWG5200-250 - 5 GS/s (10 GS/s interpolated)
- AWG5202 - AWG5200-2DC - High Bandwidth Amplified outputs
- AWG5202 - AWG5200-2HV - High Voltage outputs
- AWG5202 - AWG5200-2AC - AC Amplified outputs
- AWG5202 - AWG5200-2DIGUP - Digital up conversion (requires AWG5200-250)
- AWG5202 - AWG5200-SEQ - Sequencing
- AWG5202 - Opt. A0 - North America power plug (115 V, 60 Hz)
- AWG5202 - Opt. A1 - Universal Euro power plug (220 V, 50 Hz)
- AWG5202 - Opt. A2 - United Kingdom power plug (240 V, 50 Hz)
- AWG5202 - Opt. A3 - Australia power plug (240 V, 50 Hz)
- AWG5202 - Opt. A4 - North America power plug (240 V, 50 Hz)
- AWG5202 - Opt. A5 - Switzerland power plug (220 V, 50 Hz)
- AWG5202 - Opt. A6 - Japan power plug (100 V, 50/60 Hz)
- AWG5202 - Opt. A10 - China power plug (50 Hz)
- AWG5202 - Opt. A11 - India power plug (50 Hz)
- AWG5202 - Opt. A12 - Brazil power plug (60 Hz)
- AWG5202 - Opt. A99 - No power cord
- AWG5202 - Opt. L0 - English manual
- AWG5202 - Opt. L5 - Japanese manual
- AWG5202 - Opt. L7 - Simplified Chinese manual
- AWG5202 - Opt. L8 - Traditional Chinese manual
- AWG5202 - Opt. L10 - Russian manual
- AWG5202 - Opt. L99 - No manual
- AWG5202 - Opt. C3 - Calibration Service 3 Years
- AWG5202 - Opt. C5 - Calibration Service 5 Years
- AWG5202 - Opt. CA1 - Single Calibration or Functional Verification
- AWG5202 - Opt. D1 - Calibration Data Report
- AWG5202 - Opt. D3 - Calibration Data Report 3 Years (with Opt. C3)
- AWG5202 - Opt. D5 - Calibration Data Report 5 Years (with Opt. C5)
- AWG5202 - Opt. G3 - Complete Care 3 Years (includes loaner, scheduled calibration, and more)
- AWG5202 - Opt. G5 - Complete Care 5 Years (includes loaner, scheduled calibration, and more)
- AWG5202 - Opt. IF - Upgrade Installation Service
- AWG5202 - Opt. R3 - Repair Service 3 Years (including warranty)
- AWG5202 - Opt. R5 - Repair Service 5 Years (including warranty)
| Model | AWG5202 |
|---|
The Tektronix AWG5202 Arbitrary Waveform Generator features 4 channels, 2 GHz analog bandwidth, and 16-bit resolution with up to 10 GS/s sample rate. It supports 2 GSample memory/channel, advanced RF baseband signal generation, and seamless integration with simulation tools like MATLAB or Excel.
Ideal for precision RF signal creation, playback of captured data, real-world simulation, and synchronized multi-channel testing, all operable from the front panel or remotely via SourceXpress.
Testwall can supply the used Tektronix AWG5202, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix AWG5202.
