Tektronix BSX125
| Attribute | Value |
|---|---|
| Channel Count | 125 Channels |
| Maximum Sample Rate | 12.5 Gbps per channel |
| Memory Depth | Up to 64 Mb per channel |
| Threshold Accuracy | ±50 mV |
| Input Voltage Range | -2 V to +6 V |
| Minimum Detectable Pulse Width | 80 ps |
| Interface | USB 3.0 and PCIe |
| Operating Temperature | 0°C to 50°C |
| Power Consumption | Approximately 75 W |
| Supported Standards | MIPI, DDR, PCIe, USB, and other high-speed serial protocols |
Tektronix BSX125 Options:
- BSX125 - Opt. FEC - Forward error correction emulation
- BSX125 - Opt. UPM - User-defined detector pattern match
- BSX125 - Opt. F2 - F/2 jitter generation
- BSX125 - Opt. J-MAP - Add jitter decomposition software
- BSX125 - Opt. LDA - Add live data analysis software
- BSX125 - Opt. STR - Stressed signal generation
- BSX125 - Opt. SLD - Add stressed live data option software
- BSX125 - Opt. TXEQ - Add 4-tap Tx equalization
- BSX125 - Opt. C3 - Calibration Service 3 Years
- BSX125 - Opt. R3 - Repair Service 3 Years (including warranty)
- BSX125 - Opt. R3DW - Repair Service Coverage 3 Years (includes product warranty period). 3-year period starts at time of customer instrument purchase
| Model | BSX125 |
|---|
The Tektronix BSX125 from the BERTScope BSX-series supports error testing up to 32 Gb/s with Tx equalization, link training, FEC emulation, and intelligent pattern sequencing. Features include Eye Diagram Analysis, Jitter Mapping, and real-time BER insight with Error Location Analysis™ for advanced receiver testing.
Ideal for Gen3/Gen4 compliance testing, signal integrity analysis, and high-speed I/O validation across PCIe, SAS, USB3.1, and custom protocols, with automation support and detector pattern feedback.
Testwall can supply the used Tektronix BSX125, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix BSX125.
