Tektronix CR286A
| Attribute | Value |
|---|---|
| Frequency Range | 10 MHz to 26.5 GHz |
| Clock Recovery Standard | OC-48 / STM-16 |
| Data Rate | 2.488 Gbps |
| Input Connector Type | SMA (female) |
| Output Connector Type | SMA (female) |
| Input Voltage Range | 100 mV to 1 V peak-to-peak |
| Recovered Clock Output Level | -2 dBm to +2 dBm into 50 Ohms |
| Operating Temperature | 0°C to +50°C |
| Storage Temperature | -20°C to +60°C |
| Power Requirements | +12 VDC, supplied via external power adapter |
Tektronix CR286A Options:
- CR286A - PCIE - PCIe PLL analysis (requires 12GJ, operates at 2.5 G and 5 G only)
- CR286A - PCIE8G - PCIe PLL analysis
- CR286A - HS - Add High-sensitivity Clock Recovery (This option has no data outputs)
- CR286A - XLBW - Add Extended Loop Bandwidth in the clock recovery
- CR286A - 28GJ - Add Jitter Spectrum Analysis from 1.2 to 11.2 Gb/s
- CR286A - CA1 - Single Calibration or Functional Verification
- CR286A - C3 - Calibration Service 3 Years
- CR286A - R3 - Repair Service 3 Years (including warranty)
- CR286A - -R3DW - Repair Service Coverage 3 Years (includes product warranty period); 3-year period starts at time of customer instrument purchase
| Model | CR286A |
|---|
The Tektronix CR286A from the BERTScope Clock Recovery Series supports jitter testing with precision loop bandwidth control from 100 kHz to 12 MHz, covering data rates from 150 Mb/s to 28.6 Gb/s. Features include full/divided clock outputs, high-sensitivity inputs, programmable peaking, and integrated USB control interface.
Ideal for PCIe, USB 3.0, SATA, and serial stream validation with accurate jitter transfer function measurements, DC-coupled data path, and spectrum analyzer support for deep jitter analysis.
Testwall can supply the used Tektronix CR286A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix CR286A.
