Tektronix
Tektronix CT6
AC Current Probe Probes
1 mA to 1 A peak Current Range
DC to 1 GHz Frequency Range
350 ps Rise Time
5 mA/div minimum Sensitivity
5 mV/mA Output Voltage
| Attribute | Value |
|---|---|
| Current Range | 1 mA to 1 A peak |
| Frequency Range | DC to 1 GHz |
| Rise Time | 350 ps |
| Sensitivity | 5 mA/div minimum |
| Output Voltage | 5 mV/mA |
| Maximum Input Current (Peak) | 1 A peak pulse |
| Insertion Impedance | Less than 1 Ω (DC to 100 MHz) |
| Output Connector | SMA |
| Aperture (Inner Diameter) | 0.1 in (2.54 mm) |
| Compatible Instruments | Tektronix oscilloscopes with 50 Ω input termination |
Tektronix CT6 Options:
- CT6 - C3 - Calibration Service 3 Years
- CT6 - C5 - Calibration Service 5 Years
- CT6 - D1 - Calibration Data Report (CT6 only)
- CT6 - D3 - Calibration Data Report 3 Years (with Opt. C3)
- CT6 - D5 - Calibration Data Report 5 Years (with Opt. C5)
- CT6 - R3 - Repair Service 3 Years
- CT6 - R5 - Repair Service 5 Years
- CT6 - SILV400 - Standard Warranty Extended to 5 Years (CT6 Only)
| Model | CT6 |
|---|
The Tektronix CT6 High-Frequency Current Probe offers 2 GHz bandwidth, ultra-low inductance (<3 nH), and a compact design. Ideal for measuring rise times <200 ps and current waveforms in dense, high-speed circuits using high-bandwidth oscilloscopes.
Supports single-shot pulse, propagation delay, and differential current testing with minimal loading, designed for integration into modern signal integrity environments.
Testwall can supply the used Tektronix CT6, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix CT6.
