Tektronix DPO2004B
| Attribute | Value |
|---|---|
| Number of Channels | 4 |
| Bandwidth | 70 MHz |
| Sample Rate | 1 GS/s |
| Record Length | 1 M points on all channels |
| Vertical Resolution | 8-bit |
| Display | 7-inch WVGA color display (800 x 480 pixels) |
| Waveform Capture Rate | 5,000 waveforms per second |
| Input Impedance | 1 MΩ in parallel with 13 pF |
| Connectivity | USB Host and Device ports, CompactFlash card slot |
| Trigger Types | Edge, Pulse Width, Logic, Rise/Fall Time, Video, Serial (I2C, SPI, RS-232/422/485/UART, USB) |
Tektronix DPO2004B Options:
- DPO2004B - DPO2BND - Application bundle module option that contains the DPO2AUTO, DPO2COMP, DPO2EMBD application modules
- DPO2004B - DPO2AUTO - Automotive Serial Triggering and Analysis Module. Enables triggering on packet-level information on CAN bus and LIN bus as well as analytical tools such as digital views of the signal, bus views, packet decoding, search tools, and packet decode tables with time stamp information
- DPO2004B - DPO2COMP - Computer Serial Triggering and Analysis Module. Enables triggering on packet-level information on RS-232/422/485/UART buses as well as analytical tools such as digital views of the signal, bus views, packet decoding, search tools, and packet decode tables with time stamp information
- DPO2004B - DPO2EMBD - Embedded Serial Triggering and Analysis Module. Enables triggering on packet-level information on I2C and SPI buses as well as analytical tools such as digital views of the signal, bus views, packet decoding, search tools, and packet decode tables with time stamp information
- DPO2004B - DPO2CONN - Adds Ethernet (10/100Base-T) and video out port
- DPO2004B - Opt. A0 - North America power plug (115 V, 60 Hz)
- DPO2004B - Opt. A1 - Universal Euro power plug (220 V, 50 Hz)
- DPO2004B - Opt. A2 - United Kingdom power plug (240 V, 50 Hz)
- DPO2004B - Opt. A3 - Australia power plug (240 V, 50 Hz)
- DPO2004B - Opt. A5 - Switzerland power plug (220 V, 50 Hz)
- DPO2004B - Opt. A6 - Japan power plug (100 V, 110/120 V, 60 Hz)
- DPO2004B - Opt. A10 - China power plug (50 Hz)
- DPO2004B - Opt. A11 - India power plug (50 Hz)
- DPO2004B - Opt. A12 - Brazil power plug (60 Hz)
- DPO2004B - Opt. A99 - No power cord
- DPO2004B - Opt. L0 - English manual
- DPO2004B - Opt. L1 - French manual
- DPO2004B - Opt. L2 - Italian manual
- DPO2004B - Opt. L3 - German manual
- DPO2004B - Opt. L4 - Spanish manual
- DPO2004B - Opt. L5 - Japanese manual
- DPO2004B - Opt. L6 - Portuguese manual
- DPO2004B - Opt. L7 - Simplified Chinese manual
- DPO2004B - Opt. L8 - Traditional Chinese manual
- DPO2004B - Opt. L9 - Korean manual
- DPO2004B - Opt. L10 - Russian manual
- DPO2004B - Opt. L99 - No manual
- DPO2004B - Opt. D1 - Calibration Data Report
| Model | DPO2004B |
|---|
The Tektronix DPO2004B Mixed Signal Oscilloscope features 4 analog channels, 200 MHz bandwidth, up to 1 GS/s sample rate, and 1 M record length. It supports 16 digital channels, offering comprehensive analysis with MagniVu™ timing and Wave Inspector® controls.
Includes automated serial decoding, FFT analysis, advanced triggering, and 10.4" color display. Ideal for embedded system design and validation with extensive connectivity and optional application support.
Testwall can supply the used Tektronix DPO2004B, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix DPO2004B.
