Tektronix DPO4102B
Digital Phosphor Oscilloscope, 1 GHz 2 Ch., 5 GS/s
1 GHz Bandwidth
2 Number of Channels
5 GS/s Sample Rate
20 M points Record Length
8-bit Vertical Resolution
| Attribute | Value |
|---|---|
| Bandwidth | 1 GHz |
| Number of Channels | 2 |
| Sample Rate | 5 GS/s |
| Record Length | 20 M points |
| Vertical Resolution | 8-bit |
| Rise Time | 350 ps |
| Display | 10.4 inch WVGA color display |
| Waveform Capture Rate | up to 340,000 waveforms per second |
| Input Impedance | 1 MΩ or 50 Ω |
| Connectivity | USB, Ethernet, CompactFlash |
Tektronix DPO4102B Options:
- DPO4102B - A0 - North America power plug (115 V, 60 Hz)
- DPO4102B - A1 - Universal Euro power plug (220 V, 50 Hz)
- DPO4102B - A2 - United Kingdom power plug (240 V, 50 Hz)
- DPO4102B - A3 - Australia power plug (240 V, 50 Hz)
- DPO4102B - A5 - Switzerland power plug (220 V, 50 Hz)
- DPO4102B - A6 - Japan power plug (100 V, 50/60 Hz)
- DPO4102B - A10 - China power plug (50 Hz)
- DPO4102B - A11 - India power plug (50 Hz)
- DPO4102B - A12 - Brazil power plug (60 Hz)
- DPO4102B - A99 - No power cord
- DPO4102B - L0 - English manual
- DPO4102B - L1 - French manual
- DPO4102B - L2 - Italian manual
- DPO4102B - L3 - German manual
- DPO4102B - L4 - Spanish manual
- DPO4102B - L5 - Japanese manual
- DPO4102B - L6 - Portuguese manual
- DPO4102B - L7 - Simplified Chinese manual
- DPO4102B - L8 - Traditional Chinese manual
- DPO4102B - L9 - Korean manual
- DPO4102B - L10 - Russian manual
- DPO4102B - L99 - No manual
- DPO4102B - C3 - Calibration Service 3 Years
- DPO4102B - C5 - Calibration Service 5 Years
- DPO4102B - D1 - Calibration Data Report
- DPO4102B - D3 - Calibration Data Report 3 Years (with Opt. C3)
- DPO4102B - D5 - Calibration Data Report 5 Years (with Opt. C5)
- DPO4102B - R5 - Repair Service 5 Years (including warranty)
- DPO4102B - SILV600 - Standard warranty extended to 5 years
- DPO4102B - DPO4BND - Application bundle module enabling all functionality of DPO4AERO, DPO4AUDIO, DPO4AUTO, DPO4COMP, DPO4EMBD, DPO4ENET, DPO4LMT, DPO4PWR, DPO4USB and DPO4VID application modules
- DPO4102B - DPO4AERO - Aerospace Serial Triggering and Analysis Module (MIL-STD-1553)
- DPO4102B - DPO4AUDIO - Audio Serial Triggering and Analysis Module (I2S, LJ, RJ, TDM)
- DPO4102B - DPO4AUTO - Automotive Serial Triggering and Analysis Module (CAN and LIN)
- DPO4102B - DPO4AUTOMAX - Extended Automotive Serial Triggering and Analysis Module (CAN, LIN, and FlexRay)
- DPO4102B - DPO4COMP - Computer Serial Triggering and Analysis Module (RS-232/422/485/UART)
- DPO4102B - DPO4EMBD - Embedded Serial Triggering and Analysis Module (I2C and SPI)
- DPO4102B - DPO4ENET - Ethernet Serial Triggering and Analysis Module (10BASE-T and 100BASE-TX)
- DPO4102B - DPO4USB - USB Serial Triggering and Analysis Module (low-speed, full-speed, and high-speed)
- DPO4102B - DPO4PWR - Power Analysis Application Module
- DPO4102B - DPO4LMT - Limit and Mask Testing Application Module
- DPO4102B - DPO4VID - HDTV and Custom (nonstandard) Video Triggering and Video Picture Module
| Model | DPO4102B |
|---|
The Tektronix DPO4102B is a 2-channel digital phosphor oscilloscope offering 1 GHz bandwidth, 5 GS/s sample rate, and 20 M-point record length per channel. It includes Wave Inspector® navigation, 41 automated measurements, FFT analysis, and serial protocol support.
Compact and powerful, the DPO4102B supports advanced debugging via TekVPI® probes and a 10.4″ XGA LCD, ideal for mixed-signal and protocol analysis across industries.
Testwall can supply the used Tektronix DPO4102B, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix DPO4102B.
