Tektronix DPO4COMP
| Attribute | Value |
|---|---|
| Compatible Oscilloscope Series | DPO4000, MSO4000 Series |
| Module Type | Serial Triggering and Analysis Application Module |
| Supported Serial Standards | RS-232, RS-422, RS-485, UART |
| Trigger Modes | Start Bit, Rx/Tx Data, Parity Error, Packet End |
| Baud Rate Support | Up to 10 Mb/s |
| Data Word Length | 5, 6, 7, 8, or 9 bits configurable |
| Bus Decode Display | Yes, with color-coded overlay on waveform |
| Search and Mark Capability | Yes, search across acquired waveform records for specific events |
| Installation Method | Plug-in application module (front panel slot) |
| License Type | Hardware-based application module (no PC required) |
| Model | DPO4COMP |
|---|
The Tektronix DPO4COMP adds advanced computer-serial bus analysis to DPO/MSO4000 oscilloscopes, supporting RS-232, RS-422, RS-485, and UART protocols. It features packet-level triggering, real-time decode of ASCII/Hex/Binary, and smart search functionality for identifying signal events. Its signal workflow uses oscilloscope analog/digital inputs without external hardware.
Ideal for debugging embedded systems, this module enables accurate identification of start/stop bits, specific data, and error conditions. Export decoded data for efficient documentation and analysis.
Testwall can supply the used Tektronix DPO4COMP, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix DPO4COMP.
