Tektronix DSA71254B
| Attribute | Value |
|---|---|
| Bandwidth | 12.5 GHz |
| Sample Rate | 50 GS/s |
| Number of Channels | 4 |
| Record Length | Up to 250 Megapoints |
| Vertical Resolution | 8-bit (up to 11-bit with Hi-Res mode) |
| Rise Time | 28 ps |
| Input Impedance | 50 Ω |
| Display | 12.1-inch TFT color LCD display |
| Operating System | Windows XP Professional |
| Waveform Capture Rate | Up to 300,000 waveforms per second |
Tektronix DSA71254B Options:
- DSA71254B - A0 - Power Cord, North America
- DSA71254B - A1 - Power Cord, Universal Euro
- DSA71254B - A2 - Power Cord, United Kingdom
- DSA71254B - A3 - Power Cord, Australia
- DSA71254B - A5 - Power Cord, Switzerland
- DSA71254B - A6 - Power Cord, Japan
- DSA71254B - A10 - Power Cord, China
- DSA71254B - A11 - Power Cord, India
- DSA71254B - A99 - No power cord or AC adapter
- DSA71254B - MTH - Communication Mask Testing Software
- DSA71254B - PTH - Serial Protocol Trigger Software
- DSA71254B - PTU - Serial Protocol Trigger Software
- DSA71254B - STU - Serial Protocol Trigger Software
- DSA71254B - RTE - Real Time Eye Measurement Software
- DSA71254B - PCE - RTE module for PCI-Express
- DSA71254B - FBD - RTE module for FB-DIMM compliance
- DSA71254B - IBA - RTE module for InfiniBand
| Model | DSA71254B |
|---|
The Tektronix DSA71254B is a 12.5 GHz Digital Serial Analyzer featuring 4 matched channels for precise real-time analysis of high-speed serial signals. It supports up to 33 GHz bandwidth, 100 GS/s sampling rate, <9ps rise time, and <0.50% vertical noise with ≥5.5 ENOB. MSO models offer 16 logic channels with 80ps timing resolution.
Ideal for debugging and validating high-performance serial designs, the DSA71254B supports over 30 tailored software packages for in-depth protocol and compliance analysis.
Testwall can supply the used Tektronix DSA71254B, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix DSA71254B.
