Tektronix
Tektronix LC130
Inductance/Capacitance (LC) Meter Measurement Category
0.01 µH to 99.99 H Inductance Measurement Range
0.01 pF to 9999 µF Capacitance Measurement Range
±0.2% Basic Accuracy
1 kHz Test Frequency
| Attribute | Value |
|---|---|
| Measurement Category | Inductance/Capacitance (LC) Meter |
| Inductance Measurement Range | 0.01 µH to 99.99 H |
| Capacitance Measurement Range | 0.01 pF to 9999 µF |
| Basic Accuracy | ±0.2% |
| Test Frequency | 1 kHz |
| Display | 4-digit LCD display |
| Power Supply | 9V battery (NEDA 1604 or equivalent) |
| Operating Temperature Range | 0°C to 50°C (32°F to 122°F) |
| Dimensions | 197 mm x 92 mm x 38 mm (7.75 in x 3.6 in x 1.5 in) |
| Weight | Approximately 340 g (12 oz) with battery |
| Model | LC130 |
|---|
The Tektronix LC130 is a digital logic comparator and state analyzer designed to validate digital circuit logic with precision. It compares expected and actual logic states, storing timing data for comprehensive analysis.
Equipped with high-speed memory, advanced clocking, and sophisticated trigger capabilities, it supports detailed diagnostics of legacy systems and complex bus architectures.
Testwall can supply the used Tektronix LC130, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix LC130.
