Tektronix MDO3EMBD
| Attribute | Value |
|---|---|
| Compatible Series | MDO3000 Series Oscilloscopes |
| Module Type | Embedded Serial Triggering and Analysis Module |
| Supported Serial Buses | I2C, SPI, RS-232/422/485/UART, CAN, LIN, FlexRay, MIL-STD-1553, SENT, I2S/LJ/RJ/TDM, USB |
| Triggering Capability | Serial bus triggering on protocol-level conditions for supported bus types |
| Decode Display | Color-coded bus waveform overlays with packet-level decode directly on screen |
| Search Functionality | Automated search and mark across acquired waveform for serial bus events |
| Results Table | Tabular decode results with timestamp, data, and packet information |
| Installation Type | Application module — plugs directly into the MDO3000 application module slot |
| License Type | Hardware-based license (module must be physically installed to activate features) |
| Warranty | 1 Year |
Tektronix MDO3EMBD Options:
- MDO3EMBD - MDO3EMBD - I²C and SPI Serial Triggering and Analysis Application Module for MDO3000 Series
- MDO3000 - MDO3COMP - RS-232/422/485/UART Serial Triggering and Analysis Application Module for MDO3000 Series
- MDO3000 - MDO3AUTO - CAN/CAN FD and LIN Serial Triggering and Analysis Application Module for MDO3000 Series
- MDO3000 - MDO3FLEX - FlexRay Serial Triggering and Analysis Application Module for MDO3000 Series
- MDO3000 - MDO3AUDIO - I²S/LJ/RJ/TDM Serial Triggering and Analysis Application Module for MDO3000 Series
- MDO3000 - MDO3AERO - MIL-STD-1553 and ARINC 429 Serial Triggering and Analysis Application Module for MDO3000 Series
- MDO3000 - MDO3USB - USB Serial Triggering and Analysis Application Module for MDO3000 Series
| Model | MDO3EMBD |
|---|
The Tektronix MDO3EMBD application module transforms the MDO3000 oscilloscope into a powerful embedded serial protocol analyzer, supporting I²C and SPI standards. It offers automated packet‑level triggering, decoding, searching, and real‑time analysis directly within the scope interface, with support for up to 10 Mb/s data rates.
Designed for deep embedded debugging, it enables intelligent search functions and CSV‑exportable event tables. Integrated seamlessly with analog, digital, and RF spectrum channels, it supports license portability for flexible use.
Testwall can supply the used Tektronix MDO3EMBD, fully tested. With expert support and global delivery, Testwall ensures high‑performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix MDO3EMBD.
