Tektronix MSO4104B
| Attribute | Value |
|---|---|
| Bandwidth | 1 GHz |
| Analog Channels | 4 |
| Digital Channels | 16 |
| Sample Rate | 5 GS/s |
| Record Length | 20 M points |
| Vertical Resolution | 8 bits |
| Rise Time | 350 ps |
| Input Impedance | 1 MΩ or 50 Ω |
| Display | 10.4 inch WVGA color display |
| Connectivity | USB, Ethernet, CompactFlash |
Tektronix MSO4104B Options:
Options available for the Tektronix DPO/MSO4000 Series. Installed options vary from unit to unit – ask us for the exact configuration of the instrument you are interested in.
- MSO4104B - DPO4AERO - Aerospace serial triggering and analysis (MIL-STD-1553)
- MSO4104B - DPO4AUDIO - Audio serial triggering and analysis (I2S, LJ, RJ, TDM)
- MSO4104B - DPO4AUTO - Automotive serial triggering and analysis (CAN, LIN)
- MSO4104B - DPO4AUTOMAX - Extended automotive serial triggering and analysis (CAN, LIN, FlexRay)
- MSO4104B - DPO4COMP - Computer serial triggering and analysis (RS-232/422/485, UART)
- MSO4104B - DPO4EMBD - Embedded serial triggering and analysis (I2C, SPI)
- MSO4104B - DPO4ENET - Ethernet serial triggering and analysis (10BASE-T, 100BASE-TX)
- MSO4104B - DPO4USB - USB 2.0 serial triggering and analysis
- MSO4104B - DPO4LMT - Limit and mask testing
- MSO4104B - DPO4PWR - Power measurement and analysis
- MSO4104B - DPO4VID - Extended video triggering
- MSO4104B - DPO4BND - Application bundle (all DPO4 serial, power, limit/mask and video modules)
The Tektronix MSO4104B Mixed Signal Oscilloscope offers up to 20 analog and digital signal inputs, Wave Inspector® for waveform navigation, and deep memory on all channels. Features include 41 automated measurements, FFT analysis, and serial triggering options for protocols like I2C, USB, and CAN. A 10.4" XGA display and compact design enhance usability.
Ideal for mixed signal design debugging, the MSO4104B includes TekVPI® probe support, Ethernet/USB connectivity, and plug-and-play data handling. Lightweight and powerful, it simplifies complex signal evaluation.
Testwall can supply the used Tektronix MSO4104B, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix MSO4104B.
