Tektronix P7330
Differential Probe, 3.5 GHz TC Interface
3.5 GHz Bandwidth
100 ps Rise Time
50 Ω Input Impedance
±10 V Dynamic Range
10X Attenuation Ratio
| Attribute | Value |
|---|---|
| Bandwidth | 3.5 GHz |
| Rise Time | 100 ps |
| Input Impedance | 50 Ω |
| Dynamic Range | ±10 V |
| Attenuation Ratio | 10X |
| Maximum Input Voltage | ±15 V (DC + Peak AC) |
| Probe Interface | TekConnect |
| Compatible Oscilloscopes | Tektronix TDS/CSA7000B, TDS6000B/C, DSA/DPO70000 Series |
| Cable Length | 1.2 m (approximately 4 ft) |
| Operating Temperature | 0°C to +50°C |
Tektronix P7330 Options:
- P7330 - C3 - Calibration Service 3 Years
- P7330 - C5 - Calibration Service 5 Years
- P7330 - D3 - Calibration Data Report 3 Years (with Opt. C3)
- P7330 - D5 - Calibration Data Report 5 Years (with Opt. C5)
- P7330 - G3 - Complete Care 3 Years (includes loaner and more)
- P7330 - G5 - Complete Care 5 Years (includes loaner and more)
- P7330 - R3 - Repair Service 3 Years (including warranty)
- P7330 - R5 - Repair Service 5 Years (including warranty)
| Model | P7330 |
|---|
Tektronix P7330The Tektronix P7350 high bandwidth diffeial probes offers superb signal fidelity, meeting the needs of engineers in design and debug of technologies with very fast clock speeds and edge rates. The Tekronix P7330 provides a high bandwidth, low-circuit loading, low-noise diffeial probing solution for high speed circuit designers. The Tektronix P7350 improves usability with variable spacing and solder down capability, and a small form factor for ease of use on densely packed circuit boards with difficult-to-reach probe points. It employs a "TekConnect" interface, which preserves signal integrity to 10 GHz and beyond to meet present and future bandwidth needs. The Tektronix P7330 enables users to make time domain or frequency domain measurements on high bandwidth signals commonly found in digital IC designs, communication applications, and disk drive applications.
