Tektronix PED3202
| Attribute | Value |
|---|---|
| Number of Channels | 2 |
| Bandwidth | 200 MHz |
| Sample Rate | 1 GS/s |
| Record Length | 2,500 points per channel |
| Vertical Resolution | 8 bits |
| Vertical Sensitivity | 2 mV/div to 5 V/div |
| Time Base Range | 5 ns/div to 50 s/div |
| Input Impedance | 1 MΩ in parallel with 20 pF |
| Display | 5.7-inch color LCD |
| Connectivity | USB Host and Device ports |
Tektronix PED3202 Options:
- PED3202 - AC - AC coupled input option for PED3202
- PED3202 - DC - DC coupled input option for PED3202
- PED3202 - HCLK - Half rate clock input option for PED3202
- PED3202 - FLCLK - Full rate clock input option for PED3202
- PED3202 - A0 - North America power plug (115 V, 60 Hz)
- PED3202 - A1 - Universal Euro power plug (220 V, 50 Hz)
- PED3202 - A2 - United Kingdom power plug (240 V, 50 Hz)
- PED3202 - A6 - Japan power plug (100 V, 50/60 Hz)
- PED3202 - A10 - China power plug (50 Hz)
- PED3202 - A11 - India power plug (50 Hz)
- PED3202 - A99 - No power cord
| Model | PED3202 |
|---|
The Tektronix PED3202 is a two-channel programmable error detector capable of BER measurements up to 32 Gb/s. It supports PRBS and user-defined patterns, with flexible AC or DC coupled inputs and clock synchronization for high-speed data communications testing.
Features include automatic/manual clock alignment, threshold control, PC GUI for bathtub and jitter analysis, and compatibility with Tektronix PPG generators—ideal for receiver, component, and 100G Ethernet validation up to 40 Gb/s.
Testwall can supply the used Tektronix PED3202, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix PED3202.
