Tektronix
Tektronix TPP0850
High Voltage Probe, 800 MHz 2.5kV, 50X
850 MHz Bandwidth
10X Attenuation Ratio
10 MΩ Input Resistance
9.5 pF – 10.5 pF Input Capacitance
300 V RMS CAT II Maximum Input Voltage
| Attribute | Value |
|---|---|
| Bandwidth | 850 MHz |
| Attenuation Ratio | 10X |
| Input Resistance | 10 MΩ |
| Input Capacitance | 9.5 pF – 10.5 pF |
| Maximum Input Voltage | 300 V RMS CAT II |
| Rise Time | ≤ 500 ps |
| Cable Length | 1.3 m (4.27 ft) |
| Compensation Range | 15 pF – 25 pF |
| Compatible Oscilloscopes | Tektronix MSO/DPO5000, DPO7000, MSO/DPO4000B, and MDO4000 Series |
| Connector Type | TekVPI Probe Interface |
| Model | TPP0850 |
|---|
The Tektronix TPP0850 High-Voltage Probe offers 800 MHz bandwidth for signals up to 2500 VPeak and 1000 VRMS CAT II. It features 50X attenuation with readout coding, ideal for testing high-speed power semiconductors and SMPS circuits.
Suitable for advanced voltage environments and fast rise-time applications requiring accurate high-voltage probing.
Testwall can supply the used Tektronix TPP0850, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix TPP0850.
