Tektronix TPS2014B
| Manufacturer | Tektronix |
| Model | TPS2014B |
| Product | Digital Storage Oscilloscope, 100 MHz 4 Ch., 1 GS/s |
SKU
145240
Tektronix TPS2014B The Tektronix TPS2014B Digital Storage Oscilloscope offers unique features and familiar, user-friendly controls and menus. Its distinctive IsolatedChannel™ Technology provides confidence for damage-free circuitry while measuring and its standard battery power makes it practical for field applications. The Tektronix TPS2014B Digital Storage Oscilloscope provides powerful productivity from bench to field.Features and Specifications of the Tektronix TPS2014B Digital Storage Oscilloscope include: Features: Specifications: Benefits Applications: Isolated External Trigger Input (Impedance isolated) Battery Power: Optional Power Application Software offers broad range of power measurements Quickly document and analyze measurement results with: FFT Standard Advanced triggers to quickly capture the event of interest Quick setup and operation with: 8 hours of continuous battery operation 2 batteries installed Hot swappable Virtually unlimited freedom from AC Line Power OpenChoice® Software or Integrated CompactFlash® Mass Storage Traditional, Analog-style knobs Multilanguage User Interface Autoset Menu Autorange Waveform and setup memories Built-in, context-sensitive help Backlit menu buttons for high visibility 11 of the most critical automatic waveform measurements Industrial Power Design: Advance Electronics Design: Automotive Design and Test Education Troubleshooting Installation Maintenance Troubleshooting Installation Maintenance Electrical Characteristics: Isolated Channels: 4 Bandwidth: 100 MHz Sample Rate per channel: 1.0 GS/s Record Length: 2.5k points Display (1/4 VGA LCD): Color Battery Operation: Automatic Measurements: 11 Vertical Resolution: 8 bits (normal or with averaging) Vertica
- Benefits
- Isolated External Trigger Input (Impedance isolated)
- Battery Power:
- 8 hours of continuous battery operation
- 2 batteries installed
- Hot swappable
- Virtually unlimited freedom from AC Line Power
- Optional Power Application Software offers broad range of power measurements
- Quickly document and analyze measurement results with:
- OpenChoice® Software or
- Integrated CompactFlash® Mass Storage
- FFT Standard
- Advanced triggers to quickly capture the event of interest
- Quick setup and operation with:
- Traditional, Analog-style knobs
- Multilanguage User Interface
- Autoset Menu
- Autorange
- Waveform and setup memories
- Built-in, context-sensitive help
- Backlit menu buttons for high visibility
- 11 of the most critical automatic waveform measurements
- Applications:
- Industrial Power Design:
- Troubleshooting
- Installation
- Maintenance
- Advance Electronics Design:
- Troubleshooting
- Installation
- Maintenance
- Automotive Design and Test
- Education
- Industrial Power Design:
- Electrical Characteristics:
- Isolated Channels: 4
- Bandwidth: 100 MHz
- Sample Rate per channel: 1.0 GS/s
- Record Length: 2.5k points
- Display (1/4 VGA LCD): Color
- Battery Operation:
- Capacity for 2 hot-swappable battery packs
- 1 standard battery pack offers 4 hours of battery operation
- Optional second battery pack extends battery operation to 8 hours
- Continuous batter operation is possible by hot-swapping charged batteries
- Automatic Measurements: 11
- Vertical Resolution: 8 bits (normal or with averaging)
- Vertical Sensitivity: 2 mV to 5 V/div with calibrated fine adjustment
- DC Vertical Accuracy: ±3%
- Vertical Zoom: Vertically expand or compress a live or stopped waveform
- Max Input Voltage (1 Ω): 300 VRMS CAT II from BNC signal to BNC shell
- Float Voltage: 600 VRMS CAT II from BNC shell to earth ground
- Position Range:
- 2 mV to 200 mV/div ±1.8 V
- >200 mV to 5 V/div ±45 V
- Bandwidth Limit: 20 MHz
- Linear Dynamic Range: ±5 div
- Time Base Range: 5 ns to 50 s/div
- Time Base Accuracy: 50 ppm
- Input Impedance: 1 MΩ ±2% in parallel with 20 pF
- Input Coupling: AC, DC, GND
- Horizontal Zoom: Horizontally expand or compress a live or stopped waveform
- FFT: Standard
- RS-232, Centronics-Parallel Ports: Standard
- PC Connectivity: Standard
- Integrated CompactFlash® Mass Storage: Standard
- Power Measurements:
- Optional package that offers instantaneous:
- Power waveform analysis
- Waveform analysis
- Harmonics analysis
- Switching loss
- Phase angles
- dv/dt and di/dt cursors
- Optional package that offers instantaneous:
- Isolated External Trigger Input (Impedance isolated)
- Battery Power:
- 8 hours of continuous battery operation
- 2 batteries installed
- Hot swappable
- Virtually unlimited freedom from AC Line Power
- Optional Power Application Software offers broad range of power measurements
- Quickly document and analyze measurement results with:
- OpenChoice® Software or
- Integrated CompactFlash® Mass Storage
- FFT Standard
- Advanced triggers to quickly capture the event of interest
- Quick setup and operation with:
- Traditional, Analog-style knobs
- Multilanguage User Interface
- Autoset Menu
- Autorange
- Waveform and setup memories
- Built-in, context-sensitive help
- Backlit menu buttons for high visibility
- 11 of the most critical automatic waveform measurements
- Industrial Power Design:
- Troubleshooting
- Installation
- Maintenance
- Advance Electronics Design:
- Troubleshooting
- Installation
- Maintenance
- Automotive Design and Test
- Education
- 8 hours of continuous battery operation
- 2 batteries installed
- Hot swappable
- Virtually unlimited freedom from AC Line Power
- OpenChoice® Software or
- Integrated CompactFlash® Mass Storage
- Traditional, Analog-style knobs
- Multilanguage User Interface
- Autoset Menu
- Autorange
- Waveform and setup memories
- Built-in, context-sensitive help
- Backlit menu buttons for high visibility
- 11 of the most critical automatic waveform measurements
- Troubleshooting
- Installation
- Maintenance
- Troubleshooting
- Installation
- Maintenance
- Isolated Channels: 4
- Bandwidth: 100 MHz
- Sample Rate per channel: 1.0 GS/s
- Record Length: 2.5k points
- Display (1/4 VGA LCD): Color
- Battery Operation:
- Capacity for 2 hot-swappable battery packs
- 1 standard battery pack offers 4 hours of battery operation
- Optional second battery pack extends battery operation to 8 hours
- Continuous batter operation is possible by hot-swapping charged batteries
- Automatic Measurements: 11
- Vertical Resolution: 8 bits (normal or with averaging)
- Vertical Sensitivity: 2 mV to 5 V/div with calibrated fine adjustment
- DC Vertical Accuracy: ±3%
- Vertical Zoom: Vertically expand or compress a live or stopped waveform
- Max Input Voltage (1 Ω): 300 VRMS CAT II from BNC signal to BNC shell
- Float Voltage: 600 VRMS CAT II from BNC shell to earth ground
- Position Range:
- 2 mV to 200 mV/div ±1.8 V
- >200 mV to 5 V/div ±45 V
- Bandwidth Limit: 20 MHz
- Linear Dynamic Range: ±5 div
- Time Base Range: 5 ns to 50 s/div
- Time Base Accuracy: 50 ppm
- Input Impedance: 1 MΩ ±2% in parallel with 20 pF
- Input Coupling: AC, DC, GND
- Horizontal Zoom: Horizontally expand or compress a live or stopped waveform
- FFT: Standard
- RS-232, Centronics-Parallel Ports: Standard
- PC Connectivity: Standard
- Integrated CompactFlash® Mass Storage: Standard
- Power Measurements:
- Optional package that offers instantaneous:
- Power waveform analysis
- Waveform analysis
- Harmonics analysis
- Switching loss
- Phase angles
- dv/dt and di/dt cursors
- Optional package that offers instantaneous:
- Capacity for 2 hot-swappable battery packs
- 1 standard battery pack offers 4 hours of battery operation
- Optional second battery pack extends battery operation to 8 hours
- Continuous batter operation is possible by hot-swapping charged batteries
