Tektronix
Tektronix TS100
TDR Telephone Cable Tester
100 kHz to 1.7 GHz Frequency Range
50 Ohms Impedance
Up to 80 dB Dynamic Range
Built-in LCD touchscreen display Display Type
Spectrum Analyzer, Cable and Antenna Analysis, Power Meter Measurement Modes
| Attribute | Value |
|---|---|
| Frequency Range | 100 kHz to 1.7 GHz |
| Impedance | 50 Ohms |
| Dynamic Range | Up to 80 dB |
| Display Type | Built-in LCD touchscreen display |
| Measurement Modes | Spectrum Analyzer, Cable and Antenna Analysis, Power Meter |
| Connector Type | N-Type female RF input connector |
| Power Supply | Rechargeable lithium-ion battery, up to 4 hours operation |
| Operating Temperature | 0°C to +50°C (32°F to 122°F) |
| Dimensions | Compact handheld form factor, approximately 215 mm x 100 mm x 38 mm |
| Interface / Connectivity | USB and Ethernet connectivity for data transfer and remote operation |
Tektronix TS100 Options:
- TS100 - 01 - Adds 5 ns pulse width, coax setup menu, and adapter cable
- TS100 - 1C - Changes U.S. AC adapter/charger to 119424000 universal Euro adapter/charger (220 VAC, 1 A)
- TS100 - 2C - Changes U.S. AC adapter/charger to 119423900 United Kingdom adapter/charger (240 VAC, 1A)
- TS100 - 3C - Changes U.S. AC adapter/charger to 119423800 Australian adapter/charger (240 VAC, 1 A)
- TS100 - C3 - Three Years Calibration Service
- TS100 - C5 - Five Years Calibration Service
- TS100 - D1 - Test Data Report
- TS100 - D3 - Three Years Test Data (requires Option C3)
- TS100 - D5 - Five Years Test Data (requires Option C5)
- TS100 - L1 - French
- TS100 - L3 - German (Operates in English, German Manual)
- TS100 - L4 - Spanish/Portuguese (Spanish default)
- TS100 - L6 - Portuguese/Spanish (Portuguese default)
- TS100 - LC - Czechoslovakian (English Manual)
- TS100 - LD - Dutch/French (Dutch default)
- TS100 - LF - Finnish (English Manual)
| Model | TS100 |
|---|
The Tektronix TS100 Cable Test – Metallic features impedance, attenuation, and capacitance testing across metallic cables including coaxial, twisted pair, and shielded types. It supports up to 5000 feet length and operates within a 500 Hz to 1 MHz frequency range.
With high accuracy (±1% ±0.01 Ω) and versatile modes, it simplifies diagnostics in telecom, aerospace, and industrial settings.
Testwall can supply the used Tektronix TS100 Cable Test – Metallic, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix TS100 Cable Test – Metallic.
