Teladyne LeCroy WAVESURFER 3022
| Attribute | Value |
|---|---|
| Bandwidth | 200 MHz |
| Number of Channels | 2 |
| Sample Rate | 2 GS/s |
| Memory Depth | 10 Mpts/ch |
| Display | 7.0 inch color touchscreen LCD |
| Vertical Resolution | 8-bit (up to 12-bit with enhanced resolution) |
| Input Impedance | 1 MΩ or 50 Ω |
| Time Base Range | 1 ns/div to 1000 s/div |
| Waveform Capture Rate | 130,000 waveforms/second |
| Connectivity | USB Host, USB Device, Ethernet (LAN), HDMI |
Teladyne LeCroy WAVESURFER 3022 Options:
- WAVESURFER 3022 - USB2-GPIB - External GPIB Accessory
- WAVESURFER 3022 - WS3K-SOFTCASE - Soft Carrying Case
- WAVESURFER 3022 - WS3K-RACK - Rack Mount Accessory
- WAVESURFER 3022 - WS3K-FP-GERMAN - German Front Panel Overlay
- WAVESURFER 3022 - WS3K-FP-FRENCH - French Front Panel Overlay
- WAVESURFER 3022 - WS3K-FP-ITALIAN - Italian Front Panel Overlay
- WAVESURFER 3022 - WS3K-FP-SPANISH - Spanish Front Panel Overlay
- WAVESURFER 3022 - WS3K-FP-JAPANESE - Japanese Front Panel Overlay
- WAVESURFER 3022 - WS3K-FP-KOREAN - Korean Front Panel Overlay
- WAVESURFER 3022 - WS3K-FP-CHNES-TR - Chinese (Tr) Front Panel Overlay
- WAVESURFER 3022 - WS3K-FP-CHNES-SI - Chinese (Simp) Front Panel Overlay
- WAVESURFER 3022 - WS3K-FP-RUSSIAN - Russian Front Panel Overlay
- WAVESURFER 3022 - WS3K-MSO - MSO Software Option and 16 Channel Digital Probe Leadset
- WAVESURFER 3022 - WS3K-MSO-LICENSE - MSO License (MS Probe Not Included)
- WAVESURFER 3022 - WS3K-FG - Function Generator Option
- WAVESURFER 3022 - WS3K-AUTO - CAN and LIN Trigger and Decode Option
- WAVESURFER 3022 - WS3K-CAN FDbus TD - CAN FD Trigger and Decode Option
- WAVESURFER 3022 - WS3K-EMB - I2C, SPI, UART and RS-232 Trigger and Decode Option
- WAVESURFER 3022 - WS3K-FlexRaybus TD - FlexRay Trigger and Decode Option
| Model | WAVESURFER 3022 |
|---|
The Teledyne LeCroy WaveSurfer 3022 is part of the WaveSurfer 3000 series, featuring a 200 MHz analog bandwidth and four-channel architecture. It delivers 2 GS/s sampling (4 GS/s interleaved) with 10 Mpts of memory per channel, ensuring precise waveform capture and detailed analysis. The 10.1″ capacitive touch LCD, powered by the MAUI interface, offers intuitive operation alongside tools like WaveScan anomaly search, History Mode, and a waveform update rate of approximately 130k wfm/s.
Ideal for electronics troubleshooting, signal validation, and embedded system testing, the WaveSurfer 3022 combines high acquisition speed, deep memory, and advanced search capabilities to streamline debugging and measurement workflows.
Testwall can supply the used Teledyne LeCroy WaveSurfer 3022, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Teledyne LeCroy WaveSurfer 3022.
