Teledyne LeCroy
Teledyne LeCroy WR 9104
Oscilloscope, 1GHz,4 Ch. 20 GS/s
1 GHz Bandwidth
4 Number of Channels
5 GS/s (single channel), 2.5 GS/s (dual channel), 1.25 GS/s (all channels) Sample Rate
12.5 Mpts/ch (standard), up to 100 Mpts/ch (optional) Memory Depth
8 bits (up to 11 bits with enhanced resolution) Vertical Resolution
| Attribute | Value |
|---|---|
| Bandwidth | 1 GHz |
| Number of Channels | 4 |
| Sample Rate | 5 GS/s (single channel), 2.5 GS/s (dual channel), 1.25 GS/s (all channels) |
| Memory Depth | 12.5 Mpts/ch (standard), up to 100 Mpts/ch (optional) |
| Vertical Resolution | 8 bits (up to 11 bits with enhanced resolution) |
| Timebase Range | 200 ps/div to 1000 s/div |
| Input Impedance | 1 MΩ or 50 Ω |
| Vertical Sensitivity | 1 mV/div to 10 V/div |
| Display | 10.4-inch color LCD touchscreen |
| Connectivity | USB, Ethernet (LAN), GPIB (optional) |
Teledyne LeCroy WR 9104 Options:
- WR 9104 - MS - Mixed Signal Oscilloscope with 16 Digital Channels (WaveRunner 9104-MS)
- WR 9104 - WR9K-256GB-RSSD - 256 GB Removable Solid State Drive Option
- WR 9104 - WR9K-256GB-RSD-02 - Additional 256 GB Solid State Drive for use with RSSD option. Includes Windows 10, LeCroy Oscilloscope Software and Critical Scope Operational File Duplicates
- WR 9104 - WR9K-UPG-16GBRAM - Upgrade from 8 GB RAM to 16 GB RAM
- WR 9104 - WR9K-1553 TD - MIL-STD-1553 Trigger and Decode Option
- WR 9104 - WR9K-1553 TDME - MIL-STD-1553 Trigger, Decode, Measure/Graph, and Eye Diagram Option
- WR 9104 - WR9K-80B-8b10b TD - 8b10b Decode Option - Includes 80 bit 3.125 Gb/s serial trigger
- WR 9104 - WR9K-ARINC429BUS DME SYMBOLIC - ARINC 429 Bus Symbolic Decode, Measure/Graph, and Eye Diagram Option
- WR 9104 - WR9K-ARINC429BUS DSYMBOLIC - ARINC 429 Bus Symbolic Decode Option
- WR 9104 - WR9K-Audiobus TD - AudioBus Trigger and Decode Option
- WR 9104 - WR9K-Audiobus TDG - AudioBus Trigger, Decode, and Graph Option
- WR 9104 - WR9K-CAN FDBUS TD - CAN FD Trigger and Decode Option
- WR 9104 - WR9K-CAN FDBUS TDME - CAN FD Trigger, Decode, Measure/Graph, and Eye Diagram Option
- WR 9104 - WR9K-CAN FDBUS TDME SYMBOLIC - CAN FD Symbolic Trigger, Decode, Measure/Graph, and Eye Diagram Option
- WR 9104 - WR9K-CANBUS TD - CAN Trigger and Decode Option
- WR 9104 - WR9K-CANBUS TDME - CAN Trigger, Decode, Measure/Graph, and Eye Diagram Option
- WR 9104 - WR9K-CANBUS TDME SYMBOLIC - CAN Symbolic Trigger, Decode, Measure/Graph, and Eye Diagram Option
- WR 9104 - WR9K-DigRF3Gbus D - DigRF 3G Bus Decode Option
- WR 9104 - WR9K-DigRFV4bus D - DigRF V4 Bus Decode Option
- WR 9104 - WR9K-DPHYbus D - MIPI D-PHY CSI-2, DSI Bus Decode Option
- WR 9104 - WR9K-DPHYbus DP - MIPI D-PHY CSI-2, DSI Bus Decode and Physical Layer Test Option
- WR 9104 - WR9K-EMB TD - Bundle: includes I2C, SPI, UART-RS232 Trigger and Decode Option
- WR 9104 - WR9K-EMB TDME - Bundle: includes I2C, SPI, UART-RS232 Trigger, Decode, Measure/Graph, and Eye Diagram Option
- WR 9104 - WR9K-ENETbus D - ENET Bus Decode Option
- WR 9104 - WR9K-FCbus D - FibreChannel Decode Annotation Option
- WR 9104 - WR9K-FLEXRAYBUS TD - FlexRay Trigger and Decode Option
- WR 9104 - WR9K-FLEXRAYBUS TDMP - FlexRay Trigger, Decode, Measure/Graph and Physical Layer Option
- WR 9104 - WR9K-I2CBUS TD - I2C Trigger and Decode Option
- WR 9104 - WR9K-I2CBUS TDME - I2C Trigger, Decode, Measure/Graph, and Eye Diagram Option
- WR 9104 - WR9K-LINBUS TD - LIN Trigger and Decode Option
- WR 9104 - WR9K-LINBUS TDME - LIN Trigger, Decode, Measure/Graph, and Eye Diagram Option
- WR 9104 - WR9K-MANCHESTERbus D - Manchester Bus Decode Option
- WR 9104 - WR9K-MDIOBUS D - MDIO Decode Option
- WR 9104 - WR9K-MPHYbus D - MIPI M-PHY Bus Decode Option
- WR 9104 - WR9K-MPHYbus DP - MIPI M-PHY Bus Decode and Physical Layer Test Option
- WR 9104 - WR9K-NRZbus D - NRZ Bus Decode Option
- WR 9104 - WR9K-PCIebus D - PCIe Gen 1 Decode Option
- WR 9104 - WR9K-PROTOBUS MAG - Serial Debug Toolkit - Measure Analyze Graph Option
- WR 9104 - WR9K-ProtoSync - Decode Annotation and Protocol Analyzer Synchronization Option
- WR 9104 - WR9K-ProtoSync-BT - Decode Annotation and Protocol Analyzer+Bit Tracer Synchronization Option
- WR 9104 - WR9K-SASbus D - SAS Decode Annotation Option
- WR 9104 - WR9K-SATAbus D - SATA Decode Option
- WR 9104 - WR9K-SENTbus D - SENT Bus Decode Option
- WR 9104 - WR9K-SPACEWIREbus D - SpaceWire Decode Option
- WR 9104 - WR9K-SPIBUS TD - SPI Trigger and Decode Option
- WR 9104 - WR9K-SPIBUS TDME - SPI Trigger, Decode, Measure/Graph, and Eye Diagram Option
- WR 9104 - WR9K-SPMIbus D - SPMI Decode Option
- WR 9104 - WR9K-UART-RS232BUS TD - UART-RS232 Trigger and Decode Option
- WR 9104 - WR9K-UART-RS232BUS TDME - UART-RS232 Trigger, Decode, Measure/Graph, and Eye Diagram Option
- WR 9104 - WR9K-UNIPRObus D - MIPI UniPro Protocol Decoder Software Option
- WR 9104 - WR9K-UPG-MPHY-UNIPRObus D - MPHY to UniPro Decoder Software Upgrade (MPHY Required)
- WR 9104 - WR9K-USB2BUS TD - USB 2.0 Trigger and Decode Option
- WR 9104 - WR9K-USB2BUS TDME - USB 2.0 Trigger, Decode, Measure/Graph, and Eye Diagram Option
- WR 9104 - WR9K-USB2-HSICbus D - USB 2.0 HSIC Decode Option
- WR 9104 - QPHY-BroadR-Reach - QualiPHY Enabled BroadR-Reach Software Option
- WR 9104 - QPHY-DDR2 - QualiPHY Enabled DDR2 Software Option
- WR 9104 - QPHY-DDR3 - QualiPHY Enabled DDR3 Software Option
- WR 9104 - QPHY-1000BASE-T1 - QualiPHY Enabled 1000-BaseT1 Compliance Software Option
- WR 9104 - QPHY-ENET - QualiPHY Enabled Ethernet 10/100/1000BT Software Option
- WR 9104 - QPHY-LPDDR2 - QualiPHY Enabled LPDDR2 Software Option
- WR 9104 - QPHY-MIPI-DPHY - QualiPHY Enabled MIPI D-PHY Software Option
- WR 9104 - QPHY-MOST150 - QualiPHY Enabled MOST150 Software Option
- WR 9104 - QPHY-MOST50 - QualiPHY Enabled MOST50 Software Option
- WR 9104 - QPHY-USB - QualiPHY Enabled USB 2.0 Software Option
- WR 9104 - WR9K-DDR2-TOOLKIT - DDR2 and LPDDR2 Debug Toolkit
- WR 9104 - WR9K-DDR3-TOOLKIT - DDR3, DDR3L, LPDDR3, DDR2, and LPDDR2 Debug Toolkit
- WR 9104 - WR9K-UPG-DDR3-TOOLKIT - DDR3, DDR3L, LPDDR3, DDR2, and LPDDR2 Debug Toolkit Upgrade
- WR 9104 - WR9K-SDAIII - Single-Lane Serial Data Analysis, Eye, Jitter and Noise Measurements
- WR 9104 - WR9K-EYEDRII - Eye Doctor II - Channel and Fixture De-embedding/Emulation, Tx/Rx Equalization
- WR 9104 - WR9K-SDM - Serial Data Mask Software Package
- WR 9104 - WR9K-CBL-DE-EMBED - Cable De-Embedding Option
- WR 9104 - WR9K-AORM - Advanced Optical Recording Measurement Package
- WR 9104 - WR9K-DDA - Disk Drive Analyzer Software Package
- WR 9104 - WR9K-DDM2 - Disk Drive Measurements Software Package
- WR 9104 - WR9K-PWR - Power Analyzer Software Option
- WR 9104 - WR9K-JITKIT - Clock, Clock-Data Jitter Analysis and Views of Time, Statistical, Spectral, and Jitter Overlay
- WR 9104 - WR9K-DFP2 - Digital Filter Software Option
- WR 9104 - WR9K-EMC - EMC Pulse Parameter Software
- WR 9104 - WR9K-ET-PMT - Electrical Telecom Pulse Mask Test
- WR 9104 - WR9K-SPECTRUM - Spectrum Analyzer and Advanced FFT
- WR 9104 - WR9K-VECTORLINQ - VectorLinQ Vector Signal Analysis
- WR 9104 - WR9K-XDEV - Advanced Customization
- WR 9104 - USB2-GPIB - External USB2 to GPIB Adaptor
- WR 9104 - WR9K-RACK - WaveRunner 9000 Rackmount Kit
- WR 9104 - WR9K-CARRYCASE - WaveRunner 9000 Carrying Case
| Model | WR 9104 |
|---|
The Teledyne LeCroy WR 9104 is part of the WaveRunner series, delivering 1 GHz analog bandwidth across four channels with up to 20 GS/s sampling. Its deep internal memory stores tens of millions of points for detailed signal analysis, while the MAUI touchscreen interface ensures intuitive control with built-in serial and data analysis tools to optimize analog testing workflows.
This oscilloscope is ideal for engineers and technicians requiring high-speed measurements, waveform capture, and efficient debugging across a wide range of electronic applications.
Testwall can supply the used Teledyne LeCroy WR 9104, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Teledyne LeCroy WR 9104.
